| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_021T10_9000004210_29281cztM0_level2.evt | modeM0/AS1A10_021T10_9000004210_29281cztM0_level2_quad_clean.evt |
| Size (bytes) | 560,494,080 | 105,600,960 |
| Size | 534.5 MB | 100.7 MB |
| Events in quadrant A | 3,151,945 | 724,178 |
| Events in quadrant B | 3,514,708 | 731,297 |
| Events in quadrant C | 3,656,796 | 656,687 |
| Events in quadrant D | 6,230,638 | 652,689 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13152 | 1 |
| B | 0 | 14280 | 1 |
| C | 0 | 14762 | 1 |
| D | 0 | 22761 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6203 | 47 | 0.757698% |
| B | 6204 | 82 | 1.321728% |
| C | 6204 | 595 | 9.590587% |
| D | 6204 | 688 | 11.089620% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7403 | 6204 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7404 | 6205 | 25 | 25 | 0.34% | 0.40% |  |
| C | 7404 | 6204 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7404 | 6205 | 566 | 566 | 7.64% | 9.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11164 | 64.25 | 817 | 803 | 161.2 |
| A | 3 | 137 | 7158 | 39.41 | 817 | 803 | 161.2 |
| A | 0 | 226 | 6759 | 36.93 | 817 | 803 | 161.2 |
| B | 0 | 229 | 200477 | 1341.7 | 796 | 777 | 148.8 |
| B | 0 | 183 | 106815 | 712.43 | 796 | 777 | 148.8 |
| B | 4 | 67 | 29819 | 195.12 | 796 | 777 | 148.8 |
| C | 14 | 238 | 283305 | 1661.09 | 747 | 753 | 170.1 |
| C | 14 | 254 | 224428 | 1314.96 | 747 | 753 | 170.1 |
| C | 3 | 233 | 214000 | 1253.65 | 747 | 753 | 170.1 |
| D | 1 | 52 | 2138423 | 10737.9 | 762 | 750 | 199.1 |
| D | 8 | 195 | 486809 | 2441.56 | 762 | 750 | 199.1 |
| D | 7 | 80 | 275465 | 1379.94 | 762 | 750 | 199.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
