| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_279T01_9000004218_29369cztM0_level2.evt | modeM0/AS1T03_279T01_9000004218_29369cztM0_level2_quad_clean.evt |
| Size (bytes) | 990,201,600 | 151,280,640 |
| Size | 944.3 MB | 144.3 MB |
| Events in quadrant A | 5,278,291 | 1,000,658 |
| Events in quadrant B | 5,380,433 | 1,017,719 |
| Events in quadrant C | 8,063,041 | 971,699 |
| Events in quadrant D | 10,594,623 | 900,801 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 202 | 0 |
| B | 0 | 202 | 0 |
| C | 0 | 202 | 0 |
| D | 0 | 202 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21577 | 2 |
| B | 0 | 21926 | 2 |
| C | 0 | 30509 | 2 |
| D | 0 | 38475 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 9973 | 74 | 0.742003% |
| B | 9974 | 90 | 0.902346% |
| C | 9974 | 983 | 9.855625% |
| D | 9974 | 1256 | 12.592741% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 12523 | 9975 | 2 | 2 | 0.02% | 0.02% |  |
| B | 12524 | 9976 | 7 | 7 | 0.06% | 0.07% |  |
| C | 12524 | 9976 | 516 | 516 | 4.12% | 5.17% |  |
| D | 12524 | 9976 | 958 | 958 | 7.65% | 9.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 80308 | 298.99 | 1348 | 1323 | 264.2 |
| A | 13 | 254 | 19534 | 68.94 | 1348 | 1323 | 264.2 |
| A | 3 | 137 | 11660 | 39.13 | 1348 | 1323 | 264.2 |
| B | 10 | 245 | 28140 | 109.84 | 1329 | 1300 | 244.3 |
| B | 12 | 111 | 28003 | 109.28 | 1329 | 1300 | 244.3 |
| B | 0 | 182 | 27088 | 105.54 | 1329 | 1300 | 244.3 |
| C | 10 | 9 | 1963622 | 6569.33 | 1281 | 1294 | 298.7 |
| C | 3 | 233 | 864888 | 2891.07 | 1281 | 1294 | 298.7 |
| C | 14 | 238 | 214479 | 713.68 | 1281 | 1294 | 298.7 |
| D | 1 | 52 | 3488152 | 11608.35 | 1267 | 1239 | 300.4 |
| D | 7 | 80 | 1029834 | 3424.32 | 1267 | 1239 | 300.4 |
| D | 8 | 195 | 537824 | 1786.36 | 1267 | 1239 | 300.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
