| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_279T01_9000004218_29378cztM0_level2.evt | modeM0/AS1T03_279T01_9000004218_29378cztM0_level2_quad_clean.evt |
| Size (bytes) | 742,222,080 | 105,837,120 |
| Size | 707.8 MB | 100.9 MB |
| Events in quadrant A | 4,131,042 | 706,177 |
| Events in quadrant B | 4,523,542 | 708,529 |
| Events in quadrant C | 4,668,975 | 567,394 |
| Events in quadrant D | 8,575,816 | 629,060 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 176 | 0 |
| B | 0 | 176 | 0 |
| C | 0 | 176 | 0 |
| D | 0 | 176 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17780 | 2 |
| B | 0 | 18797 | 2 |
| C | 0 | 19296 | 2 |
| D | 0 | 31479 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8540 | 153 | 1.791569% |
| B | 8541 | 274 | 3.208055% |
| C | 8541 | 1345 | 15.747571% |
| D | 8541 | 889 | 10.408617% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9290 | 8542 | 1 | 1 | 0.01% | 0.01% |  |
| B | 9291 | 8543 | 46 | 46 | 0.50% | 0.54% |  |
| C | 9291 | 8543 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9291 | 8543 | 608 | 608 | 6.54% | 7.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 42725 | 194.75 | 1058 | 1033 | 214.1 |
| A | 13 | 254 | 17681 | 77.77 | 1058 | 1033 | 214.1 |
| A | 3 | 137 | 10273 | 43.16 | 1058 | 1033 | 214.1 |
| B | 0 | 229 | 206351 | 1026.05 | 1047 | 1021 | 200.1 |
| B | 5 | 255 | 90029 | 444.78 | 1047 | 1021 | 200.1 |
| B | 0 | 190 | 36174 | 175.66 | 1047 | 1021 | 200.1 |
| C | 14 | 238 | 477179 | 2240.29 | 907 | 913 | 212.6 |
| C | 14 | 254 | 464328 | 2179.84 | 907 | 913 | 212.6 |
| C | 3 | 233 | 149128 | 697.18 | 907 | 913 | 212.6 |
| D | 1 | 52 | 2239303 | 9379.83 | 987 | 960 | 238.6 |
| D | 12 | 33 | 974642 | 4080.24 | 987 | 960 | 238.6 |
| D | 8 | 195 | 507408 | 2122.28 | 987 | 960 | 238.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
