| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_102T05_9000004232_29430cztM0_level2.evt | modeM0/AS1A10_102T05_9000004232_29430cztM0_level2_quad_clean.evt |
| Size (bytes) | 673,223,040 | 84,559,680 |
| Size | 642.0 MB | 80.6 MB |
| Events in quadrant A | 3,286,189 | 536,742 |
| Events in quadrant B | 3,429,862 | 547,183 |
| Events in quadrant C | 5,655,623 | 516,254 |
| Events in quadrant D | 7,569,117 | 498,061 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13585 | 1 |
| B | 0 | 14007 | 1 |
| C | 0 | 21634 | 2 |
| D | 0 | 27172 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6631 | 107 | 1.613633% |
| B | 6632 | 105 | 1.583233% |
| C | 6631 | 527 | 7.947519% |
| D | 6631 | 808 | 12.185191% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7496 | 6632 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7497 | 6633 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7496 | 6632 | 47 | 47 | 0.63% | 0.71% |  |
| D | 7496 | 6632 | 670 | 670 | 8.94% | 10.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12896 | 71.24 | 851 | 835 | 169.3 |
| A | 3 | 137 | 8080 | 42.79 | 851 | 835 | 169.3 |
| A | 0 | 226 | 7410 | 38.84 | 851 | 835 | 169.3 |
| B | 10 | 245 | 40838 | 250.3 | 839 | 819 | 159.9 |
| B | 15 | 33 | 29638 | 180.25 | 839 | 819 | 159.9 |
| B | 0 | 190 | 20446 | 122.76 | 839 | 819 | 159.9 |
| C | 3 | 233 | 2301153 | 12559.3 | 787 | 791 | 183.2 |
| C | 14 | 238 | 184802 | 1004.65 | 787 | 791 | 183.2 |
| C | 14 | 254 | 86680 | 468.93 | 787 | 791 | 183.2 |
| D | 1 | 52 | 2726990 | 14471.79 | 797 | 776 | 188.4 |
| D | 15 | 143 | 628104 | 3330.1 | 797 | 776 | 188.4 |
| D | 13 | 104 | 536859 | 2845.73 | 797 | 776 | 188.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
