| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_110T02_9000004234_29448cztM0_level2.evt | modeM0/AS1A10_110T02_9000004234_29448cztM0_level2_quad_clean.evt |
| Size (bytes) | 832,527,360 | 83,298,240 |
| Size | 794.0 MB | 79.4 MB |
| Events in quadrant A | 3,749,178 | 522,485 |
| Events in quadrant B | 3,885,834 | 528,131 |
| Events in quadrant C | 4,103,137 | 510,229 |
| Events in quadrant D | 12,954,732 | 425,989 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15999 | 3 |
| B | 0 | 16283 | 3 |
| C | 0 | 16835 | 3 |
| D | 0 | 43770 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7683 | 160 | 2.082520% |
| B | 7684 | 221 | 2.876106% |
| C | 7684 | 331 | 4.307652% |
| D | 7683 | 3522 | 45.841468% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8208 | 7686 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8209 | 7687 | 3 | 3 | 0.04% | 0.04% |  |
| C | 8209 | 7687 | 1 | 1 | 0.01% | 0.01% |  |
| D | 8208 | 7686 | 2429 | 2429 | 29.59% | 31.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 13376 | 62.69 | 970 | 948 | 198.3 |
| A | 3 | 137 | 9894 | 45.12 | 970 | 948 | 198.3 |
| A | 0 | 226 | 8311 | 37.14 | 970 | 948 | 198.3 |
| B | 0 | 229 | 58497 | 310.17 | 958 | 933 | 185.6 |
| B | 12 | 111 | 23411 | 121.12 | 958 | 933 | 185.6 |
| B | 11 | 111 | 21126 | 108.8 | 958 | 933 | 185.6 |
| C | 3 | 233 | 239200 | 1092.87 | 923 | 930 | 218.0 |
| C | 14 | 238 | 171573 | 782.68 | 923 | 930 | 218.0 |
| C | 9 | 54 | 46705 | 209.96 | 923 | 930 | 218.0 |
| D | 13 | 104 | 3461663 | 18580.89 | 773 | 750 | 186.3 |
| D | 12 | 33 | 2714959 | 14572.0 | 773 | 750 | 186.3 |
| D | 7 | 80 | 2617092 | 14046.57 | 773 | 750 | 186.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
