| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_048T05_9000004250_29510cztM0_level2.evt | modeM0/AS1A10_048T05_9000004250_29510cztM0_level2_quad_clean.evt |
| Size (bytes) | 838,975,680 | 118,077,120 |
| Size | 800.1 MB | 112.6 MB |
| Events in quadrant A | 4,106,153 | 763,635 |
| Events in quadrant B | 4,229,642 | 786,012 |
| Events in quadrant C | 4,532,322 | 761,827 |
| Events in quadrant D | 11,972,258 | 679,146 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17483 | 2 |
| B | 0 | 17798 | 2 |
| C | 0 | 18612 | 2 |
| D | 0 | 41458 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8427 | 45 | 0.533998% |
| B | 8427 | 89 | 1.056129% |
| C | 8427 | 172 | 2.041059% |
| D | 8427 | 1281 | 15.201139% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 10417 | 8429 | 0 | 0 | 0.00% | 0.00% |  |
| B | 10417 | 8429 | 4 | 4 | 0.04% | 0.05% |  |
| C | 10417 | 8429 | 15 | 15 | 0.14% | 0.18% |  |
| D | 10417 | 8429 | 1224 | 1224 | 11.75% | 14.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 15557 | 68.15 | 1062 | 1040 | 213.0 |
| A | 3 | 137 | 10467 | 44.26 | 1062 | 1040 | 213.0 |
| A | 0 | 226 | 9056 | 37.63 | 1062 | 1040 | 213.0 |
| B | 12 | 111 | 25378 | 119.0 | 1062 | 1034 | 204.6 |
| B | 11 | 111 | 22950 | 107.13 | 1062 | 1034 | 204.6 |
| B | 5 | 172 | 21267 | 98.9 | 1062 | 1034 | 204.6 |
| C | 7 | 247 | 173515 | 708.03 | 1030 | 1037 | 243.6 |
| C | 14 | 238 | 170710 | 696.51 | 1030 | 1037 | 243.6 |
| C | 3 | 233 | 152142 | 620.29 | 1030 | 1037 | 243.6 |
| D | 8 | 195 | 6602261 | 28082.89 | 992 | 966 | 235.1 |
| D | 12 | 33 | 1057957 | 4496.6 | 992 | 966 | 235.1 |
| D | 7 | 238 | 234881 | 995.11 | 992 | 966 | 235.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
