| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_073T07_9000004254_29545cztM0_level2.evt | modeM0/AS1A10_073T07_9000004254_29545cztM0_level2_quad_clean.evt |
| Size (bytes) | 755,167,680 | 101,692,800 |
| Size | 720.2 MB | 97.0 MB |
| Events in quadrant A | 3,491,482 | 669,110 |
| Events in quadrant B | 3,682,506 | 692,127 |
| Events in quadrant C | 3,680,239 | 672,355 |
| Events in quadrant D | 11,560,544 | 575,155 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14459 | 2 |
| B | 0 | 15042 | 2 |
| C | 0 | 14817 | 2 |
| D | 0 | 39021 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6751 | 62 | 0.918382% |
| B | 6751 | 168 | 2.488520% |
| C | 6751 | 139 | 2.058954% |
| D | 6751 | 2257 | 33.432084% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7916 | 6752 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7916 | 6752 | 23 | 23 | 0.29% | 0.34% |  |
| C | 7916 | 6752 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7916 | 6751 | 2371 | 2371 | 29.95% | 35.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 79133 | 443.35 | 883 | 863 | 176.5 |
| A | 13 | 254 | 13161 | 69.66 | 883 | 863 | 176.5 |
| A | 3 | 137 | 8022 | 40.55 | 883 | 863 | 176.5 |
| B | 5 | 255 | 179214 | 1061.39 | 882 | 861 | 168.0 |
| B | 12 | 111 | 20169 | 114.9 | 882 | 861 | 168.0 |
| B | 11 | 111 | 18212 | 103.26 | 882 | 861 | 168.0 |
| C | 14 | 238 | 144335 | 704.33 | 865 | 872 | 203.7 |
| C | 3 | 233 | 140359 | 684.81 | 865 | 872 | 203.7 |
| C | 2 | 114 | 16040 | 74.46 | 865 | 872 | 203.7 |
| D | 8 | 195 | 7838746 | 40759.09 | 806 | 786 | 192.3 |
| D | 12 | 33 | 243149 | 1260.34 | 806 | 786 | 192.3 |
| D | 13 | 153 | 152136 | 787.05 | 806 | 786 | 192.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
