| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_286T01_9000004268_29629cztM0_level2.evt | modeM0/AS1T03_286T01_9000004268_29629cztM0_level2_quad_clean.evt |
| Size (bytes) | 509,158,080 | 115,675,200 |
| Size | 485.6 MB | 110.3 MB |
| Events in quadrant A | 3,108,398 | 766,486 |
| Events in quadrant B | 3,238,105 | 804,837 |
| Events in quadrant C | 3,391,577 | 778,281 |
| Events in quadrant D | 5,255,294 | 715,037 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13430 | 2 |
| B | 0 | 13748 | 3 |
| C | 0 | 14275 | 2 |
| D | 0 | 19923 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6286 | 39 | 0.620426% |
| B | 6285 | 74 | 1.177407% |
| C | 6285 | 161 | 2.561655% |
| D | 6285 | 513 | 8.162291% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7536 | 6287 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7535 | 6285 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7535 | 6285 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7535 | 6286 | 480 | 480 | 6.37% | 7.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 12710 | 74.89 | 802 | 786 | 159.2 |
| A | 13 | 254 | 11236 | 65.64 | 802 | 786 | 159.2 |
| A | 3 | 137 | 7550 | 42.48 | 802 | 786 | 159.2 |
| B | 0 | 189 | 18979 | 122.42 | 813 | 792 | 148.6 |
| B | 12 | 111 | 17591 | 113.07 | 813 | 792 | 148.6 |
| B | 11 | 111 | 16380 | 104.92 | 813 | 792 | 148.6 |
| C | 14 | 238 | 143221 | 778.38 | 798 | 803 | 183.0 |
| C | 3 | 233 | 80112 | 433.46 | 798 | 803 | 183.0 |
| C | 10 | 22 | 24571 | 129.9 | 798 | 803 | 183.0 |
| D | 7 | 238 | 1067115 | 5870.31 | 774 | 756 | 181.7 |
| D | 13 | 104 | 468041 | 2572.4 | 774 | 756 | 181.7 |
| D | 7 | 80 | 406508 | 2233.67 | 774 | 756 | 181.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
