| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_286T01_9000004268_29633cztM0_level2.evt | modeM0/AS1T03_286T01_9000004268_29633cztM0_level2_quad_clean.evt |
| Size (bytes) | 522,299,520 | 105,600,960 |
| Size | 498.1 MB | 100.7 MB |
| Events in quadrant A | 3,465,593 | 686,743 |
| Events in quadrant B | 3,250,422 | 710,277 |
| Events in quadrant C | 3,279,948 | 682,690 |
| Events in quadrant D | 5,356,295 | 640,207 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14936 | 2 |
| B | 0 | 14182 | 2 |
| C | 0 | 14216 | 2 |
| D | 0 | 20548 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6867 | 76 | 1.106742% |
| B | 6867 | 35 | 0.509684% |
| C | 6867 | 106 | 1.543614% |
| D | 6867 | 445 | 6.480268% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7697 | 6867 | 41 | 41 | 0.53% | 0.60% |  |
| B | 7697 | 6868 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7697 | 6868 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7697 | 6868 | 412 | 412 | 5.35% | 6.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 366469 | 2274.09 | 802 | 788 | 160.8 |
| A | 13 | 254 | 11319 | 65.49 | 802 | 788 | 160.8 |
| A | 3 | 137 | 7980 | 44.73 | 802 | 788 | 160.8 |
| B | 0 | 230 | 40270 | 259.42 | 808 | 788 | 152.2 |
| B | 0 | 190 | 24413 | 155.23 | 808 | 788 | 152.2 |
| B | 12 | 111 | 19157 | 120.7 | 808 | 788 | 152.2 |
| C | 14 | 238 | 136572 | 747.61 | 779 | 785 | 181.6 |
| C | 3 | 233 | 72220 | 393.3 | 779 | 785 | 181.6 |
| C | 2 | 114 | 16116 | 84.41 | 779 | 785 | 181.6 |
| D | 7 | 238 | 924482 | 5100.64 | 760 | 739 | 181.1 |
| D | 7 | 80 | 602566 | 3323.11 | 760 | 739 | 181.1 |
| D | 8 | 195 | 478545 | 2638.3 | 760 | 739 | 181.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
