| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_286T01_9000004268_29639cztM0_level2.evt | modeM0/AS1T03_286T01_9000004268_29639cztM0_level2_quad_clean.evt |
| Size (bytes) | 518,621,760 | 93,608,640 |
| Size | 494.6 MB | 89.3 MB |
| Events in quadrant A | 3,126,958 | 607,745 |
| Events in quadrant B | 3,248,425 | 616,181 |
| Events in quadrant C | 3,212,928 | 587,933 |
| Events in quadrant D | 5,664,959 | 557,079 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13717 | 1 |
| B | 0 | 13771 | 1 |
| C | 0 | 13708 | 1 |
| D | 0 | 21318 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6674 | 58 | 0.869044% |
| B | 6674 | 70 | 1.048846% |
| C | 6674 | 99 | 1.483368% |
| D | 6674 | 465 | 6.967336% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7534 | 6674 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7534 | 6674 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7534 | 6674 | 5 | 5 | 0.07% | 0.07% |  |
| D | 7534 | 6674 | 371 | 371 | 4.92% | 5.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 50068 | 305.37 | 797 | 781 | 161.4 |
| A | 13 | 254 | 13408 | 78.23 | 797 | 781 | 161.4 |
| A | 3 | 137 | 8072 | 45.17 | 797 | 781 | 161.4 |
| B | 10 | 245 | 49682 | 320.35 | 792 | 769 | 152.7 |
| B | 0 | 229 | 46389 | 298.79 | 792 | 769 | 152.7 |
| B | 12 | 111 | 18910 | 118.81 | 792 | 769 | 152.7 |
| C | 14 | 238 | 126235 | 702.15 | 765 | 769 | 178.7 |
| C | 10 | 22 | 37881 | 207.69 | 765 | 769 | 178.7 |
| C | 7 | 247 | 21298 | 114.89 | 765 | 769 | 178.7 |
| D | 7 | 80 | 1346796 | 7519.12 | 750 | 729 | 179.0 |
| D | 8 | 195 | 515790 | 2877.13 | 750 | 729 | 179.0 |
| D | 13 | 153 | 368401 | 2053.81 | 750 | 729 | 179.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
