| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_019T01_9000004270_29653cztM0_level2.evt | modeM0/AS1C05_019T01_9000004270_29653cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,595,018,880 | 245,966,400 |
| Size | 1.5 GB | 234.6 MB |
| Events in quadrant A | 8,170,337 | 1,599,591 |
| Events in quadrant B | 8,715,574 | 1,634,169 |
| Events in quadrant C | 8,586,015 | 1,582,954 |
| Events in quadrant D | 21,625,697 | 1,397,570 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 362 | 0 |
| B | 0 | 362 | 0 |
| C | 0 | 362 | 0 |
| D | 0 | 362 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36374 | 3 |
| B | 0 | 37278 | 3 |
| C | 0 | 37160 | 3 |
| D | 0 | 76711 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 17920 | 132 | 0.736607% |
| B | 17921 | 185 | 1.032308% |
| C | 17921 | 206 | 1.149489% |
| D | 17921 | 3403 | 18.988896% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19710 | 17921 | 3 | 3 | 0.02% | 0.02% |  |
| B | 19711 | 17923 | 19 | 19 | 0.10% | 0.11% |  |
| C | 19711 | 17923 | 1 | 1 | 0.01% | 0.01% |  |
| D | 19711 | 17922 | 3055 | 3055 | 15.50% | 17.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 38909 | 87.07 | 2101 | 2055 | 423.2 |
| A | 13 | 254 | 32643 | 72.27 | 2101 | 2055 | 423.2 |
| A | 15 | 174 | 30130 | 66.33 | 2101 | 2055 | 423.2 |
| B | 0 | 229 | 157847 | 392.33 | 2090 | 2030 | 397.2 |
| B | 10 | 245 | 131053 | 324.87 | 2090 | 2030 | 397.2 |
| B | 0 | 230 | 84718 | 208.2 | 2090 | 2030 | 397.2 |
| C | 14 | 238 | 334038 | 707.43 | 2020 | 2025 | 469.3 |
| C | 1 | 90 | 118763 | 248.74 | 2020 | 2025 | 469.3 |
| C | 3 | 233 | 89521 | 186.43 | 2020 | 2025 | 469.3 |
| D | 7 | 80 | 11397846 | 25164.46 | 1900 | 1844 | 452.9 |
| D | 8 | 195 | 1626769 | 3588.13 | 1900 | 1844 | 452.9 |
| D | 13 | 153 | 543468 | 1196.01 | 1900 | 1844 | 452.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
