| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_019T01_9000004270_29654cztM0_level2.evt | modeM0/AS1C05_019T01_9000004270_29654cztM0_level2_quad_clean.evt |
| Size (bytes) | 525,821,760 | 85,086,720 |
| Size | 501.5 MB | 81.1 MB |
| Events in quadrant A | 3,146,827 | 535,091 |
| Events in quadrant B | 3,233,243 | 544,939 |
| Events in quadrant C | 3,273,733 | 523,662 |
| Events in quadrant D | 5,816,728 | 506,318 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13765 | 2 |
| B | 0 | 13870 | 2 |
| C | 0 | 13979 | 2 |
| D | 0 | 21981 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6690 | 65 | 0.971599% |
| B | 6690 | 75 | 1.121076% |
| C | 6690 | 122 | 1.823617% |
| D | 6690 | 532 | 7.952167% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7620 | 6690 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7620 | 6690 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7620 | 6690 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7620 | 6690 | 361 | 361 | 4.74% | 5.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12168 | 68.92 | 815 | 796 | 165.0 |
| A | 3 | 137 | 8147 | 44.55 | 815 | 796 | 165.0 |
| A | 0 | 226 | 6822 | 36.52 | 815 | 796 | 165.0 |
| B | 0 | 230 | 20506 | 125.76 | 811 | 788 | 156.8 |
| B | 12 | 111 | 19239 | 117.67 | 811 | 788 | 156.8 |
| B | 11 | 111 | 17635 | 107.44 | 811 | 788 | 156.8 |
| C | 14 | 238 | 134969 | 732.36 | 784 | 788 | 183.2 |
| C | 3 | 233 | 48961 | 262.93 | 784 | 788 | 183.2 |
| C | 2 | 114 | 16337 | 84.87 | 784 | 788 | 183.2 |
| D | 7 | 80 | 1802001 | 9788.87 | 769 | 745 | 184.0 |
| D | 8 | 195 | 443070 | 2403.8 | 769 | 745 | 184.0 |
| D | 13 | 153 | 377174 | 2045.69 | 769 | 745 | 184.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
