| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_093T01_9000004274_29679cztM0_level2.evt | modeM0/AS1A10_093T01_9000004274_29679cztM0_level2_quad_clean.evt |
| Size (bytes) | 657,737,280 | 89,426,880 |
| Size | 627.3 MB | 85.3 MB |
| Events in quadrant A | 3,684,532 | 568,784 |
| Events in quadrant B | 4,309,113 | 577,961 |
| Events in quadrant C | 4,192,465 | 534,236 |
| Events in quadrant D | 7,206,698 | 486,067 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16178 | 2 |
| B | 0 | 17804 | 2 |
| C | 0 | 17379 | 2 |
| D | 0 | 26625 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7773 | 206 | 2.650199% |
| B | 7774 | 254 | 3.267301% |
| C | 7774 | 390 | 5.016722% |
| D | 7774 | 1049 | 13.493697% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7933 | 7773 | 5 | 5 | 0.06% | 0.06% |  |
| B | 7934 | 7774 | 6 | 6 | 0.08% | 0.08% |  |
| C | 7934 | 7775 | 27 | 27 | 0.34% | 0.35% |  |
| D | 7934 | 7774 | 732 | 732 | 9.23% | 9.42% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 65332 | 337.71 | 938 | 916 | 190.7 |
| A | 13 | 254 | 14477 | 71.1 | 938 | 916 | 190.7 |
| A | 3 | 137 | 9719 | 46.15 | 938 | 916 | 190.7 |
| B | 0 | 229 | 377430 | 2087.11 | 934 | 910 | 180.4 |
| B | 10 | 245 | 230545 | 1272.9 | 934 | 910 | 180.4 |
| B | 12 | 111 | 22554 | 119.98 | 934 | 910 | 180.4 |
| C | 10 | 22 | 277682 | 1319.51 | 893 | 897 | 209.8 |
| C | 14 | 238 | 169825 | 805.33 | 893 | 897 | 209.8 |
| C | 3 | 233 | 134723 | 637.99 | 893 | 897 | 209.8 |
| D | 7 | 80 | 3161624 | 15326.7 | 859 | 831 | 206.2 |
| D | 8 | 195 | 496118 | 2401.65 | 859 | 831 | 206.2 |
| D | 2 | 250 | 156888 | 756.72 | 859 | 831 | 206.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
