| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_007T01_9000004276_29716cztM0_level2.evt | modeM0/AS1A10_007T01_9000004276_29716cztM0_level2_quad_clean.evt |
| Size (bytes) | 673,894,080 | 80,619,840 |
| Size | 642.7 MB | 76.9 MB |
| Events in quadrant A | 3,358,090 | 518,022 |
| Events in quadrant B | 5,502,134 | 520,572 |
| Events in quadrant C | 7,023,036 | 479,024 |
| Events in quadrant D | 4,109,972 | 493,108 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13935 | 1 |
| B | 0 | 20424 | 1 |
| C | 0 | 25320 | 1 |
| D | 0 | 16418 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6164 | 75 | 1.216742% |
| B | 6164 | 205 | 3.325762% |
| C | 6163 | 850 | 13.791984% |
| D | 6164 | 63 | 1.022064% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7439 | 6164 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7439 | 6164 | 24 | 24 | 0.32% | 0.39% |  |
| C | 7438 | 6163 | 232 | 232 | 3.12% | 3.76% |  |
| D | 7439 | 6164 | 6 | 6 | 0.08% | 0.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 13218 | 71.63 | 870 | 855 | 172.6 |
| A | 3 | 137 | 7848 | 40.52 | 870 | 855 | 172.6 |
| A | 0 | 226 | 7389 | 37.86 | 870 | 855 | 172.6 |
| B | 6 | 159 | 1850572 | 11523.09 | 861 | 843 | 160.5 |
| B | 0 | 229 | 189792 | 1177.08 | 861 | 843 | 160.5 |
| B | 5 | 235 | 37512 | 228.43 | 861 | 843 | 160.5 |
| C | 3 | 233 | 3507369 | 18737.56 | 811 | 819 | 187.1 |
| C | 10 | 22 | 200212 | 1065.47 | 811 | 819 | 187.1 |
| C | 14 | 238 | 135492 | 719.64 | 811 | 819 | 187.1 |
| D | 8 | 195 | 696927 | 3504.56 | 841 | 820 | 198.6 |
| D | 7 | 80 | 102587 | 512.35 | 841 | 820 | 198.6 |
| D | 7 | 238 | 50127 | 248.23 | 841 | 820 | 198.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
