| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_291T01_9000004278_29788cztM0_level2.evt | modeM0/AS1T03_291T01_9000004278_29788cztM0_level2_quad_clean.evt |
| Size (bytes) | 616,325,760 | 74,831,040 |
| Size | 587.8 MB | 71.4 MB |
| Events in quadrant A | 3,635,594 | 475,112 |
| Events in quadrant B | 5,997,303 | 466,531 |
| Events in quadrant C | 3,573,527 | 442,753 |
| Events in quadrant D | 5,021,048 | 429,209 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14995 | 2 |
| B | 0 | 22041 | 2 |
| C | 0 | 14694 | 2 |
| D | 0 | 19349 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6481 | 106 | 1.635550% |
| B | 6480 | 262 | 4.043210% |
| C | 6480 | 150 | 2.314815% |
| D | 6480 | 339 | 5.231481% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7731 | 6482 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7730 | 6481 | 27 | 27 | 0.35% | 0.42% |  |
| C | 7730 | 6481 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7730 | 6481 | 228 | 228 | 2.95% | 3.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11848 | 59.71 | 940 | 927 | 182.9 |
| A | 12 | 96 | 11200 | 56.17 | 940 | 927 | 182.9 |
| A | 0 | 226 | 8219 | 39.87 | 940 | 927 | 182.9 |
| B | 6 | 159 | 1867506 | 11075.19 | 919 | 900 | 168.5 |
| B | 0 | 229 | 416332 | 2464.9 | 919 | 900 | 168.5 |
| B | 15 | 32 | 62052 | 362.83 | 919 | 900 | 168.5 |
| C | 14 | 238 | 145281 | 719.8 | 872 | 879 | 200.6 |
| C | 2 | 114 | 15707 | 73.91 | 872 | 879 | 200.6 |
| C | 3 | 233 | 11818 | 54.53 | 872 | 879 | 200.6 |
| D | 7 | 80 | 796311 | 3933.67 | 873 | 852 | 202.2 |
| D | 8 | 195 | 438772 | 2165.58 | 873 | 852 | 202.2 |
| D | 1 | 52 | 291244 | 1436.04 | 873 | 852 | 202.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
