| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_291T01_9000004278_29794cztM0_level2.evt | modeM0/AS1T03_291T01_9000004278_29794cztM0_level2_quad_clean.evt |
| Size (bytes) | 657,815,040 | 118,445,760 |
| Size | 627.3 MB | 113.0 MB |
| Events in quadrant A | 3,885,950 | 780,376 |
| Events in quadrant B | 6,508,270 | 777,707 |
| Events in quadrant C | 4,025,083 | 748,201 |
| Events in quadrant D | 4,956,769 | 720,225 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 164 | 0 |
| B | 0 | 164 | 0 |
| C | 0 | 164 | 0 |
| D | 0 | 164 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16845 | 2 |
| B | 0 | 25158 | 2 |
| C | 0 | 17022 | 2 |
| D | 0 | 19876 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8063 | 68 | 0.843359% |
| B | 8064 | 395 | 4.898313% |
| C | 8064 | 224 | 2.777778% |
| D | 8063 | 138 | 1.711522% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8498 | 8065 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8499 | 8066 | 12 | 12 | 0.14% | 0.15% |  |
| C | 8499 | 8066 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8498 | 8065 | 63 | 63 | 0.74% | 0.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 17643 | 82.01 | 1006 | 982 | 203.2 |
| A | 3 | 137 | 10278 | 45.75 | 1006 | 982 | 203.2 |
| A | 0 | 226 | 8546 | 37.23 | 1006 | 982 | 203.2 |
| B | 6 | 159 | 2380799 | 12605.88 | 992 | 967 | 188.8 |
| B | 0 | 229 | 208897 | 1101.4 | 992 | 967 | 188.8 |
| B | 12 | 111 | 23886 | 121.4 | 992 | 967 | 188.8 |
| C | 14 | 238 | 155441 | 676.29 | 970 | 973 | 228.4 |
| C | 3 | 233 | 43892 | 187.91 | 970 | 973 | 228.4 |
| C | 10 | 22 | 30307 | 128.43 | 970 | 973 | 228.4 |
| D | 8 | 195 | 439751 | 1902.15 | 971 | 943 | 230.7 |
| D | 7 | 80 | 397207 | 1717.73 | 971 | 943 | 230.7 |
| D | 7 | 238 | 271962 | 1174.82 | 971 | 943 | 230.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
