| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_291T01_9000004278_29833cztM0_level2.evt | modeM0/AS1T03_291T01_9000004278_29833cztM0_level2_quad_clean.evt |
| Size (bytes) | 782,101,440 | 75,240,000 |
| Size | 745.9 MB | 71.8 MB |
| Events in quadrant A | 3,613,480 | 498,397 |
| Events in quadrant B | 5,487,363 | 492,391 |
| Events in quadrant C | 3,561,235 | 459,792 |
| Events in quadrant D | 10,595,900 | 384,183 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14808 | 2 |
| B | 0 | 20220 | 2 |
| C | 0 | 14567 | 2 |
| D | 0 | 35896 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6353 | 109 | 1.715725% |
| B | 6353 | 168 | 2.644420% |
| C | 6353 | 158 | 2.487014% |
| D | 6353 | 2500 | 39.351487% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7708 | 6354 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7708 | 6354 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7708 | 6354 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7708 | 6354 | 2270 | 2270 | 29.45% | 35.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12758 | 64.74 | 935 | 921 | 182.8 |
| A | 0 | 226 | 8016 | 38.81 | 935 | 921 | 182.8 |
| A | 3 | 137 | 7979 | 38.6 | 935 | 921 | 182.8 |
| B | 6 | 159 | 1870784 | 11081.55 | 919 | 902 | 168.7 |
| B | 12 | 111 | 18709 | 105.53 | 919 | 902 | 168.7 |
| B | 11 | 111 | 17441 | 98.02 | 919 | 902 | 168.7 |
| C | 14 | 238 | 147653 | 745.97 | 864 | 872 | 196.8 |
| C | 3 | 233 | 26885 | 132.2 | 864 | 872 | 196.8 |
| C | 2 | 114 | 15612 | 74.91 | 864 | 872 | 196.8 |
| D | 7 | 80 | 7140652 | 41975.0 | 734 | 717 | 170.1 |
| D | 8 | 195 | 395602 | 2321.49 | 734 | 717 | 170.1 |
| D | 2 | 250 | 113667 | 664.02 | 734 | 717 | 170.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
