| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T03_9000004314_30022cztM0_level2.evt | modeM0/AS1A10_071T03_9000004314_30022cztM0_level2_quad_clean.evt |
| Size (bytes) | 530,755,200 | 75,090,240 |
| Size | 506.2 MB | 71.6 MB |
| Events in quadrant A | 3,520,193 | 470,383 |
| Events in quadrant B | 5,201,643 | 470,095 |
| Events in quadrant C | 3,475,696 | 445,647 |
| Events in quadrant D | 3,445,634 | 443,930 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14081 | 1 |
| B | 0 | 19592 | 1 |
| C | 0 | 13904 | 1 |
| D | 0 | 13750 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6362 | 102 | 1.603269% |
| B | 6363 | 178 | 2.797423% |
| C | 6363 | 145 | 2.278799% |
| D | 6363 | 55 | 0.864372% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7607 | 6363 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7608 | 6364 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7608 | 6364 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7608 | 6364 | 2 | 2 | 0.03% | 0.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 203 | 15177 | 79.77 | 905 | 891 | 179.1 |
| A | 13 | 254 | 11976 | 61.9 | 905 | 891 | 179.1 |
| A | 8 | 192 | 10323 | 52.67 | 905 | 891 | 179.1 |
| B | 6 | 159 | 1704465 | 10211.63 | 886 | 868 | 166.8 |
| B | 12 | 111 | 20278 | 116.35 | 886 | 868 | 166.8 |
| B | 10 | 247 | 19243 | 110.14 | 886 | 868 | 166.8 |
| C | 14 | 238 | 139932 | 704.65 | 847 | 854 | 197.4 |
| C | 0 | 10 | 16059 | 77.04 | 847 | 854 | 197.4 |
| C | 2 | 114 | 14798 | 70.65 | 847 | 854 | 197.4 |
| D | 8 | 195 | 147982 | 724.75 | 859 | 843 | 203.0 |
| D | 2 | 250 | 39665 | 191.22 | 859 | 843 | 203.0 |
| D | 2 | 234 | 22294 | 105.66 | 859 | 843 | 203.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
