| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T04_9000004316_30026cztM0_level2.evt | modeM0/AS1A10_071T04_9000004316_30026cztM0_level2_quad_clean.evt |
| Size (bytes) | 382,417,920 | 52,421,760 |
| Size | 364.7 MB | 50.0 MB |
| Events in quadrant A | 2,384,919 | 324,166 |
| Events in quadrant B | 3,631,449 | 321,673 |
| Events in quadrant C | 2,490,615 | 307,636 |
| Events in quadrant D | 2,760,243 | 309,076 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 94 | 0 |
| B | 0 | 94 | 0 |
| C | 0 | 94 | 0 |
| D | 0 | 94 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9928 | 1 |
| B | 0 | 14246 | 1 |
| C | 0 | 10267 | 1 |
| D | 0 | 11274 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4625 | 189 | 4.086486% |
| B | 4625 | 311 | 6.724324% |
| C | 4625 | 268 | 5.794595% |
| D | 4625 | 190 | 4.108108% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4720 | 4627 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4720 | 4627 | 1 | 1 | 0.02% | 0.02% |  |
| C | 4720 | 4627 | 5 | 5 | 0.11% | 0.11% |  |
| D | 4720 | 4627 | 59 | 59 | 1.25% | 1.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8782 | 64.47 | 616 | 603 | 126.9 |
| A | 3 | 137 | 6535 | 46.76 | 616 | 603 | 126.9 |
| A | 0 | 226 | 5246 | 36.6 | 616 | 603 | 126.9 |
| B | 6 | 159 | 1263730 | 10423.66 | 599 | 583 | 121.2 |
| B | 12 | 111 | 15326 | 121.66 | 599 | 583 | 121.2 |
| B | 11 | 111 | 14202 | 112.39 | 599 | 583 | 121.2 |
| C | 14 | 238 | 94313 | 673.26 | 584 | 587 | 139.2 |
| C | 3 | 233 | 53810 | 382.32 | 584 | 587 | 139.2 |
| C | 2 | 16 | 42779 | 303.08 | 584 | 587 | 139.2 |
| D | 7 | 80 | 378060 | 2623.19 | 596 | 582 | 143.9 |
| D | 8 | 195 | 114879 | 794.28 | 596 | 582 | 143.9 |
| D | 2 | 250 | 19407 | 130.82 | 596 | 582 | 143.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
