| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T06_9000004324_30073cztM0_level2.evt | modeM0/AS1A10_071T06_9000004324_30073cztM0_level2_quad_clean.evt |
| Size (bytes) | 842,791,680 | 126,584,640 |
| Size | 803.7 MB | 120.7 MB |
| Events in quadrant A | 4,500,044 | 850,473 |
| Events in quadrant B | 7,115,938 | 843,324 |
| Events in quadrant C | 4,549,886 | 812,808 |
| Events in quadrant D | 8,710,527 | 662,221 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 196 | 0 |
| B | 0 | 196 | 0 |
| C | 0 | 196 | 0 |
| D | 0 | 196 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19855 | 3 |
| B | 0 | 28974 | 2 |
| C | 0 | 19814 | 2 |
| D | 0 | 32357 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 9573 | 142 | 1.483339% |
| B | 9573 | 240 | 2.507051% |
| C | 9574 | 188 | 1.963652% |
| D | 9574 | 1859 | 19.417172% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 10268 | 9576 | 1 | 1 | 0.01% | 0.01% |  |
| B | 10268 | 9576 | 1 | 1 | 0.01% | 0.01% |  |
| C | 10269 | 9577 | 0 | 0 | 0.00% | 0.00% |  |
| D | 10269 | 9577 | 1558 | 1558 | 15.17% | 16.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 192 | 24319 | 99.45 | 1155 | 1129 | 233.2 |
| A | 3 | 1 | 21343 | 86.69 | 1155 | 1129 | 233.2 |
| A | 13 | 254 | 16376 | 65.39 | 1155 | 1129 | 233.2 |
| B | 6 | 159 | 2629281 | 11941.71 | 1131 | 1100 | 220.1 |
| B | 0 | 229 | 29563 | 129.33 | 1131 | 1100 | 220.1 |
| B | 12 | 111 | 28095 | 122.66 | 1131 | 1100 | 220.1 |
| C | 14 | 238 | 177347 | 674.34 | 1104 | 1111 | 261.3 |
| C | 3 | 233 | 25901 | 94.86 | 1104 | 1111 | 261.3 |
| C | 2 | 114 | 22958 | 83.59 | 1104 | 1111 | 261.3 |
| D | 13 | 104 | 4643041 | 19616.23 | 993 | 973 | 236.6 |
| D | 8 | 195 | 163746 | 687.84 | 993 | 973 | 236.6 |
| D | 2 | 250 | 58445 | 242.86 | 993 | 973 | 236.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
