| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_019T01_9000004332_30102cztM0_level2.evt | modeM0/AS1C05_019T01_9000004332_30102cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,426,527,360 | 334,177,920 |
| Size | 1.3 GB | 318.7 MB |
| Events in quadrant A | 8,275,202 | 2,264,232 |
| Events in quadrant B | 14,076,203 | 2,252,458 |
| Events in quadrant C | 8,674,153 | 2,194,890 |
| Events in quadrant D | 10,960,475 | 2,168,068 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36846 | 3 |
| B | 0 | 55458 | 3 |
| C | 0 | 37476 | 3 |
| D | 0 | 44849 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 366 | 0 |
| B | 0 | 366 | 0 |
| C | 0 | 366 | 0 |
| D | 0 | 366 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18036 | 96 | 0.532269% |
| B | 18037 | 349 | 1.934912% |
| C | 18037 | 363 | 2.012530% |
| D | 18037 | 422 | 2.339635% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20046 | 18039 | 3 | 3 | 0.01% | 0.02% |  |
| B | 20047 | 18040 | 55 | 55 | 0.27% | 0.30% |  |
| C | 20047 | 18040 | 0 | 0 | 0.00% | 0.00% |  |
| D | 20047 | 18040 | 261 | 261 | 1.30% | 1.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 68512 | 157.25 | 2112 | 2069 | 422.5 |
| A | 8 | 192 | 37209 | 83.17 | 2112 | 2069 | 422.5 |
| A | 13 | 254 | 35687 | 79.56 | 2112 | 2069 | 422.5 |
| B | 6 | 159 | 5285883 | 13406.34 | 2082 | 2026 | 394.1 |
| B | 4 | 171 | 476796 | 1204.6 | 2082 | 2026 | 394.1 |
| B | 0 | 190 | 95565 | 237.33 | 2082 | 2026 | 394.1 |
| C | 14 | 238 | 393357 | 832.53 | 2027 | 2036 | 470.0 |
| C | 3 | 233 | 247816 | 522.89 | 2027 | 2036 | 470.0 |
| C | 14 | 254 | 92011 | 191.42 | 2027 | 2036 | 470.0 |
| D | 1 | 52 | 2188411 | 4513.67 | 2036 | 1987 | 484.4 |
| D | 8 | 195 | 483019 | 993.05 | 2036 | 1987 | 484.4 |
| D | 13 | 138 | 207087 | 423.41 | 2036 | 1987 | 484.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
