| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_097T03_9000004336_30146cztM0_level2.evt | modeM0/AS1A10_097T03_9000004336_30146cztM0_level2_quad_clean.evt |
| Size (bytes) | 534,813,120 | 82,284,480 |
| Size | 510.0 MB | 78.5 MB |
| Events in quadrant A | 3,246,390 | 526,434 |
| Events in quadrant B | 5,082,693 | 519,653 |
| Events in quadrant C | 4,134,198 | 481,727 |
| Events in quadrant D | 3,289,669 | 507,173 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13774 | 1 |
| B | 0 | 19827 | 1 |
| C | 0 | 16748 | 1 |
| D | 0 | 13893 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6548 | 57 | 0.870495% |
| B | 6549 | 78 | 1.191022% |
| C | 6549 | 581 | 8.871583% |
| D | 6549 | 34 | 0.519163% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7488 | 6549 | 8 | 8 | 0.11% | 0.12% |  |
| B | 7489 | 6549 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7489 | 6549 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7489 | 6550 | 7 | 7 | 0.09% | 0.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 128079 | 785.68 | 805 | 789 | 162.0 |
| A | 8 | 192 | 13219 | 76.72 | 805 | 789 | 162.0 |
| A | 13 | 254 | 12809 | 74.19 | 805 | 789 | 162.0 |
| B | 6 | 159 | 1907324 | 12392.29 | 794 | 771 | 153.8 |
| B | 0 | 190 | 30008 | 190.04 | 794 | 771 | 153.8 |
| B | 3 | 209 | 23329 | 146.62 | 794 | 771 | 153.8 |
| C | 3 | 233 | 732613 | 4211.3 | 744 | 751 | 173.8 |
| C | 14 | 238 | 268385 | 1540.03 | 744 | 751 | 173.8 |
| C | 14 | 254 | 208730 | 1196.76 | 744 | 751 | 173.8 |
| D | 8 | 195 | 182032 | 959.16 | 777 | 761 | 189.0 |
| D | 12 | 227 | 51655 | 269.3 | 777 | 761 | 189.0 |
| D | 13 | 249 | 31355 | 161.88 | 777 | 761 | 189.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
