| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_097T03_9000004336_30166cztM0_level2.evt | modeM0/AS1A10_097T03_9000004336_30166cztM0_level2_quad_clean.evt |
| Size (bytes) | 667,892,160 | 114,422,400 |
| Size | 637.0 MB | 109.1 MB |
| Events in quadrant A | 3,319,834 | 762,551 |
| Events in quadrant B | 5,192,488 | 775,951 |
| Events in quadrant C | 7,581,424 | 734,302 |
| Events in quadrant D | 3,709,624 | 754,074 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13610 | 2 |
| B | 0 | 19557 | 2 |
| C | 0 | 27050 | 2 |
| D | 0 | 14908 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6290 | 68 | 1.081081% |
| B | 6290 | 127 | 2.019078% |
| C | 6289 | 728 | 11.575767% |
| D | 6289 | 92 | 1.462872% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7635 | 6291 | 6 | 6 | 0.08% | 0.10% |  |
| B | 7635 | 6291 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7634 | 6290 | 182 | 182 | 2.38% | 2.89% |  |
| D | 7634 | 6290 | 56 | 56 | 0.73% | 0.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 32350 | 188.6 | 846 | 832 | 167.1 |
| A | 8 | 192 | 23246 | 134.13 | 846 | 832 | 167.1 |
| A | 13 | 254 | 11464 | 63.62 | 846 | 832 | 167.1 |
| B | 6 | 159 | 1813814 | 11437.92 | 846 | 826 | 158.5 |
| B | 0 | 230 | 33218 | 204.36 | 846 | 826 | 158.5 |
| B | 0 | 190 | 18499 | 111.5 | 846 | 826 | 158.5 |
| C | 3 | 233 | 4205018 | 22084.73 | 825 | 834 | 190.4 |
| C | 14 | 238 | 129377 | 675.24 | 825 | 834 | 190.4 |
| C | 15 | 208 | 18315 | 91.83 | 825 | 834 | 190.4 |
| D | 8 | 195 | 183260 | 900.63 | 844 | 829 | 202.6 |
| D | 2 | 250 | 88143 | 431.05 | 844 | 829 | 202.6 |
| D | 11 | 176 | 83184 | 406.57 | 844 | 829 | 202.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
