| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T15_9000004346_30209cztM0_level2.evt | modeM0/AS1A10_071T15_9000004346_30209cztM0_level2_quad_clean.evt |
| Size (bytes) | 521,717,760 | 96,863,040 |
| Size | 497.5 MB | 92.4 MB |
| Events in quadrant A | 3,256,096 | 640,589 |
| Events in quadrant B | 5,059,353 | 656,443 |
| Events in quadrant C | 3,278,862 | 615,433 |
| Events in quadrant D | 3,788,783 | 590,948 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13295 | 2 |
| B | 0 | 18864 | 2 |
| C | 0 | 13369 | 3 |
| D | 0 | 15153 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6158 | 44 | 0.714518% |
| B | 6158 | 89 | 1.445274% |
| C | 6157 | 82 | 1.331817% |
| D | 6157 | 89 | 1.445509% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7528 | 6159 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7528 | 6159 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7527 | 6158 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7527 | 6158 | 62 | 62 | 0.82% | 1.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 192 | 25467 | 148.47 | 838 | 825 | 166.0 |
| A | 13 | 254 | 10001 | 55.29 | 838 | 825 | 166.0 |
| A | 3 | 137 | 7741 | 41.67 | 838 | 825 | 166.0 |
| B | 6 | 159 | 1758720 | 11204.49 | 836 | 819 | 156.9 |
| B | 0 | 190 | 31381 | 194.8 | 836 | 819 | 156.9 |
| B | 12 | 111 | 18671 | 113.78 | 836 | 819 | 156.9 |
| C | 14 | 238 | 131418 | 701.95 | 801 | 807 | 186.1 |
| C | 2 | 114 | 14745 | 74.91 | 801 | 807 | 186.1 |
| C | 3 | 233 | 10307 | 51.06 | 801 | 807 | 186.1 |
| D | 8 | 195 | 313310 | 1673.07 | 790 | 773 | 186.8 |
| D | 7 | 223 | 241265 | 1287.4 | 790 | 773 | 186.8 |
| D | 13 | 104 | 188654 | 1005.76 | 790 | 773 | 186.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
