| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T15_9000004346_30212cztM0_level2.evt | modeM0/AS1A10_071T15_9000004346_30212cztM0_level2_quad_clean.evt |
| Size (bytes) | 554,172,480 | 74,188,800 |
| Size | 528.5 MB | 70.8 MB |
| Events in quadrant A | 3,322,312 | 454,976 |
| Events in quadrant B | 5,168,028 | 459,702 |
| Events in quadrant C | 3,383,200 | 439,667 |
| Events in quadrant D | 4,455,045 | 424,076 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13930 | 3 |
| B | 0 | 20381 | 2 |
| C | 0 | 13974 | 2 |
| D | 0 | 17515 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6705 | 72 | 1.073826% |
| B | 6705 | 142 | 2.117823% |
| C | 6705 | 100 | 1.491424% |
| D | 6705 | 183 | 2.729306% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7515 | 6706 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7515 | 6705 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7515 | 6705 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7515 | 6706 | 112 | 112 | 1.49% | 1.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 192 | 22958 | 128.49 | 855 | 839 | 172.1 |
| A | 13 | 254 | 11356 | 61.09 | 855 | 839 | 172.1 |
| A | 3 | 137 | 8678 | 45.54 | 855 | 839 | 172.1 |
| B | 6 | 159 | 1806585 | 11022.1 | 845 | 825 | 163.8 |
| B | 0 | 190 | 42646 | 255.27 | 845 | 825 | 163.8 |
| B | 12 | 111 | 20441 | 119.73 | 845 | 825 | 163.8 |
| C | 14 | 238 | 131348 | 683.32 | 814 | 821 | 191.0 |
| C | 3 | 233 | 46919 | 241.33 | 814 | 821 | 191.0 |
| C | 2 | 114 | 15840 | 78.63 | 814 | 821 | 191.0 |
| D | 1 | 52 | 610598 | 3153.79 | 810 | 791 | 193.4 |
| D | 7 | 223 | 396923 | 2048.71 | 810 | 791 | 193.4 |
| D | 8 | 195 | 246654 | 1271.55 | 810 | 791 | 193.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
