| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_007T01_9000004350_30227cztM0_level2.evt | modeM0/AS1A10_007T01_9000004350_30227cztM0_level2_quad_clean.evt |
| Size (bytes) | 572,129,280 | 93,407,040 |
| Size | 545.6 MB | 89.1 MB |
| Events in quadrant A | 3,505,903 | 583,275 |
| Events in quadrant B | 5,511,029 | 591,092 |
| Events in quadrant C | 3,663,316 | 578,129 |
| Events in quadrant D | 4,151,679 | 567,518 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14950 | 1 |
| B | 0 | 21996 | 1 |
| C | 0 | 15139 | 1 |
| D | 0 | 16697 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7303 | 138 | 1.889634% |
| B | 7304 | 191 | 2.615005% |
| C | 7304 | 162 | 2.217963% |
| D | 7304 | 117 | 1.601862% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7813 | 7305 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7814 | 7305 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7814 | 7306 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7814 | 7306 | 9 | 9 | 0.12% | 0.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 192 | 13039 | 66.4 | 905 | 886 | 183.0 |
| A | 13 | 254 | 12898 | 65.63 | 905 | 886 | 183.0 |
| A | 3 | 137 | 9134 | 45.07 | 905 | 886 | 183.0 |
| B | 6 | 159 | 1994055 | 11527.4 | 891 | 868 | 172.9 |
| B | 12 | 111 | 21491 | 119.27 | 891 | 868 | 172.9 |
| B | 11 | 111 | 20114 | 111.3 | 891 | 868 | 172.9 |
| C | 14 | 238 | 142631 | 694.74 | 870 | 875 | 204.0 |
| C | 3 | 233 | 108951 | 529.68 | 870 | 875 | 204.0 |
| C | 2 | 114 | 16587 | 77.0 | 870 | 875 | 204.0 |
| D | 8 | 195 | 307856 | 1445.9 | 880 | 858 | 212.3 |
| D | 7 | 223 | 256788 | 1205.38 | 880 | 858 | 212.3 |
| D | 1 | 52 | 165110 | 773.6 | 880 | 858 | 212.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
