| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T16_9000004348_30215cztM0_level2.evt | modeM0/AS1A10_071T16_9000004348_30215cztM0_level2_quad_clean.evt |
| Size (bytes) | 346,599,360 | 45,250,560 |
| Size | 330.5 MB | 43.2 MB |
| Events in quadrant A | 2,047,580 | 275,328 |
| Events in quadrant B | 3,251,732 | 275,182 |
| Events in quadrant C | 2,363,569 | 263,796 |
| Events in quadrant D | 2,548,638 | 260,517 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8719 | 1 |
| B | 0 | 12670 | 1 |
| C | 0 | 9611 | 1 |
| D | 0 | 10022 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 86 | 0 |
| B | 0 | 86 | 0 |
| C | 0 | 86 | 0 |
| D | 0 | 86 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4192 | 177 | 4.222328% |
| B | 4192 | 241 | 5.749046% |
| C | 4192 | 205 | 4.890267% |
| D | 4192 | 180 | 4.293893% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4392 | 4193 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4392 | 4193 | 1 | 1 | 0.02% | 0.02% |  |
| C | 4392 | 4193 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4392 | 4193 | 36 | 36 | 0.82% | 0.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 192 | 10524 | 91.46 | 527 | 515 | 109.4 |
| A | 13 | 254 | 7303 | 62.03 | 527 | 515 | 109.4 |
| A | 3 | 137 | 5680 | 47.2 | 527 | 515 | 109.4 |
| B | 6 | 159 | 1182335 | 11396.8 | 520 | 505 | 103.7 |
| B | 12 | 111 | 13225 | 122.66 | 520 | 505 | 103.7 |
| B | 11 | 111 | 12312 | 113.86 | 520 | 505 | 103.7 |
| C | 3 | 233 | 295595 | 2448.69 | 505 | 506 | 120.5 |
| C | 14 | 238 | 80682 | 665.31 | 505 | 506 | 120.5 |
| C | 2 | 114 | 9890 | 77.87 | 505 | 506 | 120.5 |
| D | 1 | 52 | 352580 | 2880.82 | 508 | 495 | 122.2 |
| D | 7 | 223 | 159357 | 1299.84 | 508 | 495 | 122.2 |
| D | 8 | 195 | 73788 | 599.69 | 508 | 495 | 122.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
