| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T20_9000004354_30315cztM0_level2.evt | modeM0/AS1A10_071T20_9000004354_30315cztM0_level2_quad_clean.evt |
| Size (bytes) | 465,370,560 | 66,646,080 |
| Size | 443.8 MB | 63.6 MB |
| Events in quadrant A | 2,649,785 | 426,445 |
| Events in quadrant B | 4,550,647 | 426,727 |
| Events in quadrant C | 3,765,162 | 378,997 |
| Events in quadrant D | 2,755,385 | 401,891 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11275 | 1 |
| B | 0 | 17519 | 1 |
| C | 0 | 14728 | 1 |
| D | 0 | 11916 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5476 | 35 | 0.639153% |
| B | 5476 | 125 | 2.282688% |
| C | 5476 | 1547 | 28.250548% |
| D | 5476 | 64 | 1.168736% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5476 | 5476 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5476 | 5476 | 14 | 14 | 0.26% | 0.26% |  |
| C | 5476 | 5476 | 5 | 5 | 0.09% | 0.09% |  |
| D | 5476 | 5476 | 51 | 51 | 0.93% | 0.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 239 | 77052 | 563.37 | 663 | 649 | 135.6 |
| A | 8 | 192 | 10952 | 75.97 | 663 | 649 | 135.6 |
| A | 13 | 254 | 8731 | 59.59 | 663 | 649 | 135.6 |
| B | 6 | 159 | 1462022 | 11325.6 | 653 | 636 | 129.0 |
| B | 6 | 36 | 508340 | 3934.66 | 653 | 636 | 129.0 |
| B | 12 | 111 | 16048 | 119.44 | 653 | 636 | 129.0 |
| C | 14 | 254 | 605440 | 4268.45 | 593 | 597 | 141.7 |
| C | 14 | 238 | 576725 | 4065.8 | 593 | 597 | 141.7 |
| C | 3 | 233 | 242931 | 1710.18 | 593 | 597 | 141.7 |
| D | 13 | 249 | 188986 | 1174.16 | 635 | 619 | 160.4 |
| D | 2 | 250 | 50025 | 307.96 | 635 | 619 | 160.4 |
| D | 1 | 52 | 47416 | 291.7 | 635 | 619 | 160.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
