| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T14_9000004362_30339cztM0_level2.evt | modeM0/AS1A10_053T14_9000004362_30339cztM0_level2_quad_clean.evt |
| Size (bytes) | 384,698,880 | 51,197,760 |
| Size | 366.9 MB | 48.8 MB |
| Events in quadrant A | 2,139,643 | 330,642 |
| Events in quadrant B | 3,075,904 | 331,334 |
| Events in quadrant C | 2,218,658 | 319,570 |
| Events in quadrant D | 3,974,656 | 316,762 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 74 | 0 |
| B | 0 | 74 | 0 |
| C | 0 | 74 | 0 |
| D | 0 | 74 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8653 | 1 |
| B | 0 | 11189 | 1 |
| C | 0 | 8874 | 1 |
| D | 0 | 14061 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3552 | 86 | 2.421171% |
| B | 3552 | 139 | 3.913288% |
| C | 3552 | 122 | 3.434685% |
| D | 3552 | 1021 | 28.744369% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4882 | 3552 | 1 | 1 | 0.02% | 0.03% |  |
| B | 4882 | 3552 | 5 | 5 | 0.10% | 0.14% |  |
| C | 4882 | 3553 | 1 | 1 | 0.02% | 0.03% |  |
| D | 4882 | 3553 | 891 | 891 | 18.25% | 25.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 203 | 152726 | 1486.62 | 511 | 502 | 102.4 |
| A | 8 | 192 | 13741 | 129.29 | 511 | 502 | 102.4 |
| A | 13 | 254 | 6608 | 59.63 | 511 | 502 | 102.4 |
| B | 6 | 159 | 1074424 | 11309.72 | 505 | 495 | 95.0 |
| B | 0 | 190 | 16373 | 167.21 | 505 | 495 | 95.0 |
| B | 12 | 111 | 11015 | 110.79 | 505 | 495 | 95.0 |
| C | 3 | 233 | 212184 | 1867.45 | 490 | 493 | 113.4 |
| C | 14 | 238 | 84226 | 738.66 | 490 | 493 | 113.4 |
| C | 2 | 114 | 8378 | 69.56 | 490 | 493 | 113.4 |
| D | 13 | 104 | 2183302 | 21973.92 | 418 | 410 | 99.3 |
| D | 2 | 250 | 79307 | 794.21 | 418 | 410 | 99.3 |
| D | 13 | 249 | 51535 | 514.65 | 418 | 410 | 99.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
