| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T17_9000004366_30368cztM0_level2.evt | modeM0/AS1A10_053T17_9000004366_30368cztM0_level2_quad_clean.evt |
| Size (bytes) | 572,552,640 | 67,671,360 |
| Size | 546.0 MB | 64.5 MB |
| Events in quadrant A | 3,748,558 | 414,826 |
| Events in quadrant B | 5,168,264 | 416,185 |
| Events in quadrant C | 4,496,361 | 392,321 |
| Events in quadrant D | 3,508,808 | 394,181 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14938 | 2 |
| B | 0 | 19131 | 2 |
| C | 0 | 17646 | 4 |
| D | 0 | 14323 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6170 | 157 | 2.544571% |
| B | 6171 | 110 | 1.782531% |
| C | 6170 | 194 | 3.144246% |
| D | 6170 | 51 | 0.826580% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7530 | 6170 | 62 | 62 | 0.82% | 1.00% |  |
| B | 7531 | 6171 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7530 | 6170 | 10 | 10 | 0.13% | 0.16% |  |
| D | 7530 | 6170 | 15 | 15 | 0.20% | 0.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 208933 | 1192.5 | 889 | 875 | 174.5 |
| A | 12 | 96 | 80748 | 457.8 | 889 | 875 | 174.5 |
| A | 8 | 192 | 25175 | 139.28 | 889 | 875 | 174.5 |
| B | 6 | 159 | 1700405 | 10386.95 | 883 | 865 | 163.6 |
| B | 12 | 111 | 18864 | 110.0 | 883 | 865 | 163.6 |
| B | 11 | 111 | 17720 | 103.01 | 883 | 865 | 163.6 |
| C | 3 | 233 | 1033699 | 5440.71 | 838 | 849 | 189.8 |
| C | 14 | 238 | 139056 | 728.03 | 838 | 849 | 189.8 |
| C | 0 | 10 | 33879 | 173.99 | 838 | 849 | 189.8 |
| D | 8 | 195 | 152269 | 720.99 | 848 | 830 | 210.0 |
| D | 2 | 250 | 37750 | 175.77 | 848 | 830 | 210.0 |
| D | 2 | 234 | 27194 | 125.52 | 848 | 830 | 210.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
