| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T17_9000004366_30370cztM0_level2.evt | modeM0/AS1A10_053T17_9000004366_30370cztM0_level2_quad_clean.evt |
| Size (bytes) | 573,180,480 | 89,199,360 |
| Size | 546.6 MB | 85.1 MB |
| Events in quadrant A | 3,584,233 | 578,895 |
| Events in quadrant B | 5,184,411 | 581,780 |
| Events in quadrant C | 4,621,085 | 549,252 |
| Events in quadrant D | 3,544,053 | 552,760 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14423 | 2 |
| B | 0 | 19229 | 2 |
| C | 0 | 17931 | 2 |
| D | 0 | 14346 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6280 | 125 | 1.990446% |
| B | 6280 | 169 | 2.691083% |
| C | 6280 | 370 | 5.891720% |
| D | 6280 | 65 | 1.035032% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7525 | 6280 | 32 | 32 | 0.43% | 0.51% |  |
| B | 7525 | 6280 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7525 | 6280 | 106 | 106 | 1.41% | 1.69% |  |
| D | 7525 | 6281 | 14 | 14 | 0.19% | 0.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 207640 | 1226.33 | 859 | 846 | 168.6 |
| A | 15 | 192 | 32627 | 188.47 | 859 | 846 | 168.6 |
| A | 8 | 192 | 19543 | 110.88 | 859 | 846 | 168.6 |
| B | 6 | 159 | 1795871 | 11216.12 | 853 | 836 | 160.0 |
| B | 6 | 36 | 20638 | 123.73 | 853 | 836 | 160.0 |
| B | 12 | 111 | 18980 | 113.37 | 853 | 836 | 160.0 |
| C | 3 | 233 | 1251952 | 6662.62 | 820 | 828 | 187.8 |
| C | 14 | 238 | 136099 | 720.36 | 820 | 828 | 187.8 |
| C | 0 | 10 | 23165 | 118.95 | 820 | 828 | 187.8 |
| D | 8 | 195 | 157588 | 786.09 | 830 | 814 | 199.4 |
| D | 2 | 250 | 99330 | 493.97 | 830 | 814 | 199.4 |
| D | 1 | 52 | 50189 | 247.57 | 830 | 814 | 199.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
