| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_006T01_9000004370_30382cztM0_level2.evt | modeM0/AS1T04_006T01_9000004370_30382cztM0_level2_quad_clean.evt |
| Size (bytes) | 580,682,880 | 100,779,840 |
| Size | 553.8 MB | 96.1 MB |
| Events in quadrant A | 3,504,076 | 671,558 |
| Events in quadrant B | 5,655,655 | 675,389 |
| Events in quadrant C | 3,476,926 | 645,741 |
| Events in quadrant D | 4,528,251 | 624,960 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14431 | 2 |
| B | 0 | 21028 | 2 |
| C | 0 | 14220 | 2 |
| D | 0 | 17634 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6227 | 136 | 2.184037% |
| B | 6227 | 388 | 6.230930% |
| C | 6227 | 150 | 2.408865% |
| D | 6227 | 228 | 3.661474% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8732 | 6227 | 17 | 17 | 0.19% | 0.27% |  |
| B | 8732 | 6227 | 81 | 81 | 0.93% | 1.30% |  |
| C | 8732 | 6228 | 2 | 2 | 0.02% | 0.03% |  |
| D | 8732 | 6228 | 167 | 167 | 1.91% | 2.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 68810 | 389.27 | 873 | 858 | 174.6 |
| A | 14 | 239 | 31954 | 178.14 | 873 | 858 | 174.6 |
| A | 8 | 192 | 28438 | 158.0 | 873 | 858 | 174.6 |
| B | 6 | 159 | 1822093 | 11344.96 | 861 | 843 | 160.5 |
| B | 5 | 255 | 339203 | 2107.72 | 861 | 843 | 160.5 |
| B | 4 | 187 | 38490 | 234.51 | 861 | 843 | 160.5 |
| C | 14 | 238 | 138587 | 716.93 | 830 | 838 | 192.1 |
| C | 3 | 233 | 69203 | 355.81 | 830 | 838 | 192.1 |
| C | 0 | 10 | 15895 | 78.37 | 830 | 838 | 192.1 |
| D | 13 | 104 | 899364 | 4594.03 | 829 | 813 | 195.6 |
| D | 8 | 195 | 167666 | 853.07 | 829 | 813 | 195.6 |
| D | 13 | 249 | 108963 | 552.94 | 829 | 813 | 195.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
