| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_019T04_9000004376_30416cztM0_level2.evt | modeM0/AS1C05_019T04_9000004376_30416cztM0_level2_quad_clean.evt |
| Size (bytes) | 585,869,760 | 117,737,280 |
| Size | 558.7 MB | 112.3 MB |
| Events in quadrant A | 3,676,699 | 774,587 |
| Events in quadrant B | 5,753,516 | 777,188 |
| Events in quadrant C | 3,700,699 | 762,396 |
| Events in quadrant D | 4,115,536 | 741,357 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15925 | 2 |
| B | 0 | 22503 | 3 |
| C | 0 | 15794 | 2 |
| D | 0 | 17287 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7333 | 71 | 0.968226% |
| B | 7332 | 117 | 1.595745% |
| C | 7332 | 268 | 3.655210% |
| D | 7332 | 150 | 2.045827% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7713 | 7335 | 27 | 27 | 0.35% | 0.37% |  |
| B | 7712 | 7333 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7712 | 7333 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7712 | 7334 | 113 | 113 | 1.47% | 1.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 244272 | 1405.11 | 859 | 841 | 173.2 |
| A | 14 | 239 | 75374 | 430.21 | 859 | 841 | 173.2 |
| A | 8 | 192 | 32802 | 184.48 | 859 | 841 | 173.2 |
| B | 6 | 159 | 2165782 | 13289.73 | 859 | 836 | 162.9 |
| B | 0 | 229 | 131301 | 800.87 | 859 | 836 | 162.9 |
| B | 15 | 32 | 34529 | 206.83 | 859 | 836 | 162.9 |
| C | 14 | 238 | 219030 | 1118.08 | 833 | 837 | 195.1 |
| C | 14 | 254 | 116268 | 591.5 | 833 | 837 | 195.1 |
| C | 10 | 22 | 53749 | 271.14 | 833 | 837 | 195.1 |
| D | 13 | 249 | 264495 | 1333.19 | 833 | 810 | 197.8 |
| D | 8 | 195 | 241685 | 1217.86 | 833 | 810 | 197.8 |
| D | 13 | 104 | 229006 | 1153.75 | 833 | 810 | 197.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
