| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T03_9000004380_30470cztM0_level2.evt | modeM0/AS1A10_058T03_9000004380_30470cztM0_level2_quad_clean.evt |
| Size (bytes) | 570,337,920 | 117,616,320 |
| Size | 543.9 MB | 112.2 MB |
| Events in quadrant A | 3,609,417 | 821,800 |
| Events in quadrant B | 5,037,212 | 815,133 |
| Events in quadrant C | 4,061,144 | 736,648 |
| Events in quadrant D | 4,142,551 | 753,611 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14735 | 1 |
| B | 0 | 19025 | 1 |
| C | 0 | 16243 | 1 |
| D | 0 | 16470 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6233 | 158 | 2.534895% |
| B | 6234 | 169 | 2.710940% |
| C | 6234 | 1106 | 17.741418% |
| D | 6234 | 185 | 2.967597% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7508 | 6234 | 33 | 33 | 0.44% | 0.53% |  |
| B | 7509 | 6235 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7509 | 6235 | 25 | 25 | 0.33% | 0.40% |  |
| D | 7509 | 6235 | 74 | 74 | 0.99% | 1.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 268931 | 1578.23 | 862 | 849 | 169.9 |
| A | 8 | 192 | 13637 | 75.28 | 862 | 849 | 169.9 |
| A | 13 | 254 | 12226 | 66.98 | 862 | 849 | 169.9 |
| B | 6 | 159 | 1677583 | 10718.08 | 837 | 821 | 156.4 |
| B | 0 | 229 | 34957 | 218.2 | 837 | 821 | 156.4 |
| B | 4 | 171 | 28326 | 175.82 | 837 | 821 | 156.4 |
| C | 14 | 238 | 388109 | 2243.64 | 750 | 756 | 172.6 |
| C | 14 | 254 | 356800 | 2062.29 | 750 | 756 | 172.6 |
| C | 15 | 208 | 144982 | 835.39 | 750 | 756 | 172.6 |
| D | 13 | 104 | 547171 | 2857.69 | 816 | 798 | 191.2 |
| D | 7 | 238 | 215870 | 1124.89 | 816 | 798 | 191.2 |
| D | 8 | 195 | 170987 | 890.14 | 816 | 798 | 191.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
