| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T04_9000004382_30487cztM0_level2.evt | modeM0/AS1A10_058T04_9000004382_30487cztM0_level2_quad_clean.evt |
| Size (bytes) | 588,280,320 | 98,521,920 |
| Size | 561.0 MB | 94.0 MB |
| Events in quadrant A | 3,435,395 | 655,205 |
| Events in quadrant B | 5,818,834 | 645,042 |
| Events in quadrant C | 3,731,780 | 606,619 |
| Events in quadrant D | 4,368,200 | 601,215 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14553 | 1 |
| B | 0 | 22017 | 2 |
| C | 0 | 15519 | 1 |
| D | 0 | 17475 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6818 | 68 | 0.997360% |
| B | 6818 | 352 | 5.162804% |
| C | 6818 | 159 | 2.332062% |
| D | 6818 | 160 | 2.346729% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7638 | 6819 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7638 | 6819 | 182 | 182 | 2.38% | 2.67% |  |
| C | 7638 | 6819 | 28 | 28 | 0.37% | 0.41% |  |
| D | 7638 | 6819 | 121 | 121 | 1.58% | 1.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 61112 | 351.68 | 859 | 842 | 171.4 |
| A | 4 | 2 | 44427 | 254.32 | 859 | 842 | 171.4 |
| A | 13 | 254 | 13747 | 75.3 | 859 | 842 | 171.4 |
| B | 6 | 159 | 1950799 | 12241.9 | 832 | 812 | 159.3 |
| B | 0 | 229 | 512113 | 3209.91 | 832 | 812 | 159.3 |
| B | 0 | 190 | 28608 | 174.5 | 832 | 812 | 159.3 |
| C | 3 | 233 | 370301 | 1966.12 | 803 | 807 | 187.9 |
| C | 14 | 238 | 130351 | 689.32 | 803 | 807 | 187.9 |
| C | 0 | 10 | 84369 | 444.64 | 803 | 807 | 187.9 |
| D | 12 | 218 | 345932 | 1771.36 | 817 | 796 | 194.8 |
| D | 8 | 195 | 292729 | 1498.31 | 817 | 796 | 194.8 |
| D | 13 | 104 | 155710 | 795.07 | 817 | 796 | 194.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
