| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_019T04_9000004388_30503cztM0_level2.evt | modeM0/AS1C05_019T04_9000004388_30503cztM0_level2_quad_clean.evt |
| Size (bytes) | 353,856,960 | 61,741,440 |
| Size | 337.5 MB | 58.9 MB |
| Events in quadrant A | 2,083,468 | 407,322 |
| Events in quadrant B | 3,337,697 | 405,043 |
| Events in quadrant C | 2,265,839 | 385,171 |
| Events in quadrant D | 2,744,757 | 376,903 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8861 | 1 |
| B | 0 | 12942 | 1 |
| C | 0 | 9354 | 1 |
| D | 0 | 11076 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 84 | 0 |
| B | 0 | 84 | 0 |
| C | 0 | 84 | 0 |
| D | 0 | 84 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4193 | 30 | 0.715478% |
| B | 4193 | 118 | 2.814214% |
| C | 4193 | 118 | 2.814214% |
| D | 4192 | 96 | 2.290076% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4473 | 4194 | 3 | 3 | 0.07% | 0.07% |  |
| B | 4473 | 4194 | 5 | 5 | 0.11% | 0.12% |  |
| C | 4473 | 4194 | 34 | 34 | 0.76% | 0.81% |  |
| D | 4472 | 4193 | 63 | 63 | 1.41% | 1.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 18195 | 165.44 | 528 | 515 | 106.9 |
| A | 8 | 192 | 14552 | 131.35 | 528 | 515 | 106.9 |
| A | 3 | 1 | 8119 | 71.15 | 528 | 515 | 106.9 |
| B | 6 | 159 | 1217996 | 12055.45 | 520 | 506 | 101.0 |
| B | 0 | 229 | 24068 | 233.31 | 520 | 506 | 101.0 |
| B | 5 | 172 | 20921 | 202.15 | 520 | 506 | 101.0 |
| C | 10 | 22 | 167852 | 1404.09 | 502 | 504 | 119.2 |
| C | 14 | 238 | 81420 | 678.9 | 502 | 504 | 119.2 |
| C | 3 | 233 | 40230 | 333.31 | 502 | 504 | 119.2 |
| D | 8 | 195 | 347907 | 2905.85 | 505 | 491 | 119.6 |
| D | 2 | 250 | 263775 | 2202.16 | 505 | 491 | 119.6 |
| D | 13 | 249 | 46029 | 380.89 | 505 | 491 | 119.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
