| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_019T04_9000004388_30518cztM0_level2.evt | modeM0/AS1C05_019T04_9000004388_30518cztM0_level2_quad_clean.evt |
| Size (bytes) | 681,059,520 | 126,564,480 |
| Size | 649.5 MB | 120.7 MB |
| Events in quadrant A | 3,637,093 | 858,631 |
| Events in quadrant B | 6,383,431 | 842,185 |
| Events in quadrant C | 4,322,475 | 821,714 |
| Events in quadrant D | 5,761,029 | 773,789 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16124 | 2 |
| B | 0 | 24697 | 2 |
| C | 0 | 18133 | 2 |
| D | 0 | 22357 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7712 | 85 | 1.102178% |
| B | 7713 | 425 | 5.510178% |
| C | 7713 | 460 | 5.963957% |
| D | 7713 | 723 | 9.373785% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8132 | 7714 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8133 | 7715 | 43 | 43 | 0.53% | 0.56% |  |
| C | 8133 | 7715 | 43 | 43 | 0.53% | 0.56% |  |
| D | 8133 | 7715 | 463 | 463 | 5.69% | 6.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 15500 | 77.12 | 937 | 915 | 189.1 |
| A | 8 | 192 | 12979 | 63.79 | 937 | 915 | 189.1 |
| A | 3 | 137 | 9336 | 44.53 | 937 | 915 | 189.1 |
| B | 6 | 159 | 2284144 | 13043.34 | 922 | 897 | 175.1 |
| B | 0 | 229 | 393992 | 2245.61 | 922 | 897 | 175.1 |
| B | 15 | 32 | 40185 | 224.44 | 922 | 897 | 175.1 |
| C | 3 | 233 | 635160 | 3016.45 | 895 | 897 | 210.3 |
| C | 14 | 238 | 144981 | 685.24 | 895 | 897 | 210.3 |
| C | 10 | 22 | 23770 | 108.78 | 895 | 897 | 210.3 |
| D | 12 | 218 | 1304249 | 6309.5 | 873 | 848 | 206.6 |
| D | 8 | 195 | 549651 | 2656.64 | 873 | 848 | 206.6 |
| D | 1 | 52 | 263800 | 1272.9 | 873 | 848 | 206.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
