| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T15_9000004392_30532cztM0_level2.evt | modeM0/AS1A10_053T15_9000004392_30532cztM0_level2_quad_clean.evt |
| Size (bytes) | 679,636,800 | 85,561,920 |
| Size | 648.2 MB | 81.6 MB |
| Events in quadrant A | 3,593,495 | 535,760 |
| Events in quadrant B | 5,970,129 | 529,773 |
| Events in quadrant C | 3,807,729 | 509,932 |
| Events in quadrant D | 6,709,999 | 499,459 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15322 | 1 |
| B | 0 | 23099 | 1 |
| C | 0 | 15900 | 1 |
| D | 0 | 24860 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7416 | 116 | 1.564186% |
| B | 7416 | 290 | 3.910464% |
| C | 7417 | 246 | 3.316705% |
| D | 7417 | 690 | 9.302953% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7596 | 7418 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7596 | 7418 | 31 | 31 | 0.41% | 0.42% |  |
| C | 7597 | 7419 | 51 | 51 | 0.67% | 0.69% |  |
| D | 7597 | 7419 | 500 | 500 | 6.58% | 6.74% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 192 | 18424 | 93.36 | 923 | 903 | 187.7 |
| A | 13 | 254 | 13775 | 68.59 | 923 | 903 | 187.7 |
| A | 8 | 192 | 13356 | 66.36 | 923 | 903 | 187.7 |
| B | 6 | 159 | 2119118 | 12091.64 | 905 | 881 | 175.2 |
| B | 6 | 36 | 159603 | 906.04 | 905 | 881 | 175.2 |
| B | 4 | 171 | 49030 | 274.85 | 905 | 881 | 175.2 |
| C | 3 | 233 | 149733 | 730.53 | 871 | 876 | 203.8 |
| C | 14 | 238 | 149140 | 727.62 | 871 | 876 | 203.8 |
| C | 10 | 22 | 75880 | 368.09 | 871 | 876 | 203.8 |
| D | 1 | 52 | 1781946 | 8515.63 | 866 | 845 | 209.2 |
| D | 13 | 104 | 1022049 | 4882.48 | 866 | 845 | 209.2 |
| D | 8 | 195 | 404906 | 1931.86 | 866 | 845 | 209.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
