| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T23_9000004404_30580cztM0_level2.evt | modeM0/AS1A10_053T23_9000004404_30580cztM0_level2_quad_clean.evt |
| Size (bytes) | 338,618,880 | 48,965,760 |
| Size | 322.9 MB | 46.7 MB |
| Events in quadrant A | 2,081,550 | 302,738 |
| Events in quadrant B | 3,295,125 | 302,082 |
| Events in quadrant C | 2,117,642 | 291,159 |
| Events in quadrant D | 2,473,583 | 289,370 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 86 | 0 |
| B | 0 | 86 | 0 |
| C | 0 | 86 | 0 |
| D | 0 | 86 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8745 | 1 |
| B | 0 | 12975 | 1 |
| C | 0 | 8761 | 1 |
| D | 0 | 10057 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4216 | 74 | 1.755218% |
| B | 4217 | 167 | 3.960161% |
| C | 4217 | 117 | 2.774484% |
| D | 4217 | 62 | 1.470240% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4556 | 4217 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4556 | 4217 | 17 | 17 | 0.37% | 0.40% |  |
| C | 4557 | 4218 | 1 | 1 | 0.02% | 0.02% |  |
| D | 4556 | 4217 | 7 | 7 | 0.15% | 0.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 11249 | 97.87 | 533 | 520 | 109.6 |
| A | 8 | 192 | 10922 | 94.88 | 533 | 520 | 109.6 |
| A | 13 | 254 | 7716 | 65.64 | 533 | 520 | 109.6 |
| B | 6 | 159 | 1140728 | 11068.36 | 521 | 508 | 103.0 |
| B | 6 | 36 | 88983 | 858.85 | 521 | 508 | 103.0 |
| B | 12 | 111 | 12777 | 119.1 | 521 | 508 | 103.0 |
| C | 14 | 238 | 81836 | 685.53 | 502 | 504 | 118.6 |
| C | 3 | 233 | 35633 | 296.09 | 502 | 504 | 118.6 |
| C | 0 | 10 | 23698 | 195.5 | 502 | 504 | 118.6 |
| D | 8 | 195 | 183984 | 1503.02 | 514 | 500 | 122.1 |
| D | 12 | 227 | 156722 | 1279.7 | 514 | 500 | 122.1 |
| D | 1 | 52 | 88566 | 721.4 | 514 | 500 | 122.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
