| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_055T01_9000004414_30628cztM0_level2.evt | modeM0/AS1A10_055T01_9000004414_30628cztM0_level2_quad_clean.evt |
| Size (bytes) | 140,915,520 | 4,498,560 |
| Size | 134.4 MB | 4.3 MB |
| Events in quadrant A | 893,702 | 9,608 |
| Events in quadrant B | 1,219,672 | 8,546 |
| Events in quadrant C | 957,793 | 8,463 |
| Events in quadrant D | 1,103,721 | 9,111 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3738 | 1 |
| B | 0 | 4400 | 1 |
| C | 0 | 3983 | 3 |
| D | 0 | 4303 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 28 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1333 | 65 | 4.876219% |
| B | 1333 | 112 | 8.402101% |
| C | 1332 | 156 | 11.711712% |
| D | 1332 | 52 | 3.903904% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2638 | 1334 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2638 | 1334 | 0 | 0 | 0.00% | 0.00% |  |
| C | 2637 | 1333 | 10 | 10 | 0.38% | 0.75% |  |
| D | 2637 | 1333 | 0 | 0 | 0.00% | 0.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 192 | 9137 | 193.18 | 229 | 225 | 46.1 |
| A | 13 | 254 | 2394 | 47.02 | 229 | 225 | 46.1 |
| A | 0 | 226 | 1924 | 36.83 | 229 | 225 | 46.1 |
| B | 6 | 159 | 342110 | 7950.3 | 223 | 219 | 43.0 |
| B | 12 | 111 | 4625 | 102.46 | 223 | 219 | 43.0 |
| B | 11 | 111 | 4303 | 94.97 | 223 | 219 | 43.0 |
| C | 0 | 10 | 54085 | 1060.19 | 217 | 218 | 50.8 |
| C | 14 | 238 | 41747 | 817.36 | 217 | 218 | 50.8 |
| C | 14 | 254 | 9485 | 182.39 | 217 | 218 | 50.8 |
| D | 8 | 195 | 247322 | 4740.34 | 222 | 217 | 52.1 |
| D | 12 | 218 | 14524 | 274.46 | 222 | 217 | 52.1 |
| D | 2 | 234 | 3746 | 67.7 | 222 | 217 | 52.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
