| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_094T80_9000004424_30674cztM0_level2.evt | modeM0/AS1A10_094T80_9000004424_30674cztM0_level2_quad_clean.evt |
| Size (bytes) | 610,603,200 | 129,078,720 |
| Size | 582.3 MB | 123.1 MB |
| Events in quadrant A | 3,334,029 | 911,414 |
| Events in quadrant B | 4,951,850 | 892,887 |
| Events in quadrant C | 3,193,722 | 870,756 |
| Events in quadrant D | 6,606,046 | 813,981 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13485 | 1 |
| B | 0 | 18962 | 1 |
| C | 0 | 13130 | 1 |
| D | 0 | 24064 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6017 | 114 | 1.894632% |
| B | 6017 | 145 | 2.409839% |
| C | 6017 | 129 | 2.143926% |
| D | 6018 | 791 | 13.143902% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7272 | 6018 | 41 | 41 | 0.56% | 0.68% |  |
| B | 7272 | 6018 | 25 | 25 | 0.34% | 0.42% |  |
| C | 7272 | 6018 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7273 | 6019 | 819 | 819 | 11.26% | 13.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 280604 | 1786.84 | 788 | 774 | 156.6 |
| A | 8 | 192 | 11460 | 68.23 | 788 | 774 | 156.6 |
| A | 13 | 254 | 11167 | 66.36 | 788 | 774 | 156.6 |
| B | 6 | 159 | 1628100 | 11488.38 | 761 | 745 | 141.7 |
| B | 4 | 81 | 204672 | 1439.63 | 761 | 745 | 141.7 |
| B | 0 | 190 | 93744 | 656.53 | 761 | 745 | 141.7 |
| C | 14 | 238 | 123709 | 717.49 | 740 | 744 | 171.4 |
| C | 3 | 233 | 106217 | 615.43 | 740 | 744 | 171.4 |
| C | 0 | 10 | 42575 | 244.08 | 740 | 744 | 171.4 |
| D | 8 | 195 | 1585762 | 9190.64 | 736 | 720 | 172.5 |
| D | 12 | 227 | 1210559 | 7015.08 | 736 | 720 | 172.5 |
| D | 13 | 249 | 559120 | 3237.8 | 736 | 720 | 172.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
