| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T14_9000004430_30699cztM0_level2.evt | modeM0/AS1A10_058T14_9000004430_30699cztM0_level2_quad_clean.evt |
| Size (bytes) | 723,850,560 | 74,946,240 |
| Size | 690.3 MB | 71.5 MB |
| Events in quadrant A | 4,037,574 | 467,600 |
| Events in quadrant B | 5,371,876 | 474,475 |
| Events in quadrant C | 3,913,398 | 448,921 |
| Events in quadrant D | 8,156,266 | 419,728 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16045 | 3 |
| B | 0 | 20377 | 2 |
| C | 0 | 15687 | 2 |
| D | 0 | 28964 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6575 | 159 | 2.418251% |
| B | 6575 | 72 | 1.095057% |
| C | 6575 | 324 | 4.927757% |
| D | 6575 | 391 | 5.946768% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7770 | 6575 | 120 | 120 | 1.54% | 1.83% |  |
| B | 7770 | 6575 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7769 | 6574 | 35 | 35 | 0.45% | 0.53% |  |
| D | 7770 | 6575 | 370 | 370 | 4.76% | 5.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 733237 | 4353.58 | 849 | 836 | 168.2 |
| A | 8 | 192 | 26597 | 153.13 | 849 | 836 | 168.2 |
| A | 13 | 254 | 12809 | 71.17 | 849 | 836 | 168.2 |
| B | 6 | 159 | 1846542 | 11522.02 | 853 | 832 | 160.2 |
| B | 0 | 190 | 160832 | 998.81 | 853 | 832 | 160.2 |
| B | 12 | 111 | 19259 | 115.03 | 853 | 832 | 160.2 |
| C | 3 | 233 | 389026 | 2083.17 | 807 | 813 | 186.4 |
| C | 14 | 238 | 203820 | 1089.34 | 807 | 813 | 186.4 |
| C | 14 | 254 | 93446 | 497.07 | 807 | 813 | 186.4 |
| D | 8 | 195 | 4918536 | 25992.35 | 807 | 788 | 189.2 |
| D | 2 | 250 | 56549 | 294.72 | 807 | 788 | 189.2 |
| D | 12 | 218 | 40634 | 210.6 | 807 | 788 | 189.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
