| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T44_9000004434_30719cztM0_level2.evt | modeM0/AS1A10_071T44_9000004434_30719cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,693,393,280 | 395,547,840 |
| Size | 2.5 GB | 377.2 MB |
| Events in quadrant A | 15,914,248 | 2,675,888 |
| Events in quadrant B | 22,230,285 | 2,651,402 |
| Events in quadrant C | 17,881,201 | 2,479,121 |
| Events in quadrant D | 23,789,596 | 2,374,612 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 534 | 0 |
| B | 0 | 534 | 0 |
| C | 0 | 534 | 0 |
| D | 0 | 534 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 63801 | 5 |
| B | 0 | 83271 | 5 |
| C | 0 | 69905 | 5 |
| D | 0 | 89613 | 5 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 57 | 0 |
| B | 0 | 57 | 0 |
| C | 0 | 57 | 0 |
| D | 0 | 57 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 26158 | 702 | 2.683691% |
| B | 26158 | 973 | 3.719703% |
| C | 26158 | 1481 | 5.661748% |
| D | 26159 | 1734 | 6.628694% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 31908 | 26158 | 98 | 98 | 0.31% | 0.37% |  |
| B | 31908 | 26158 | 156 | 156 | 0.49% | 0.60% |  |
| C | 31908 | 26158 | 451 | 451 | 1.41% | 1.72% |  |
| D | 31909 | 26159 | 1427 | 1427 | 4.47% | 5.46% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 1092007 | 1519.58 | 3638 | 3589 | 716.3 |
| A | 8 | 192 | 794567 | 1104.31 | 3638 | 3589 | 716.3 |
| A | 13 | 254 | 49459 | 64.04 | 3638 | 3589 | 716.3 |
| B | 6 | 159 | 7137444 | 10781.68 | 3553 | 3481 | 661.7 |
| B | 6 | 36 | 578513 | 869.06 | 3553 | 3481 | 661.7 |
| B | 5 | 255 | 290053 | 433.1 | 3553 | 3481 | 661.7 |
| C | 3 | 233 | 2041569 | 2627.5 | 3370 | 3407 | 775.7 |
| C | 10 | 22 | 1987281 | 2557.51 | 3370 | 3407 | 775.7 |
| C | 14 | 238 | 552807 | 708.26 | 3370 | 3407 | 775.7 |
| D | 8 | 195 | 7318661 | 8340.48 | 3380 | 3336 | 877.1 |
| D | 10 | 253 | 1625266 | 1849.22 | 3380 | 3336 | 877.1 |
| D | 13 | 249 | 697951 | 791.96 | 3380 | 3336 | 877.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
