| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T35_9000004438_30744cztM0_level2.evt | modeM0/AS1A10_053T35_9000004438_30744cztM0_level2_quad_clean.evt |
| Size (bytes) | 559,339,200 | 110,643,840 |
| Size | 533.4 MB | 105.5 MB |
| Events in quadrant A | 3,536,402 | 729,025 |
| Events in quadrant B | 5,200,969 | 744,693 |
| Events in quadrant C | 3,553,696 | 726,440 |
| Events in quadrant D | 4,227,526 | 716,536 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14327 | 1 |
| B | 0 | 19456 | 1 |
| C | 0 | 14550 | 1 |
| D | 0 | 16564 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6227 | 92 | 1.477437% |
| B | 6227 | 99 | 1.589851% |
| C | 6227 | 110 | 1.766501% |
| D | 6226 | 201 | 3.228397% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7542 | 6228 | 68 | 68 | 0.90% | 1.09% |  |
| B | 7542 | 6227 | 12 | 12 | 0.16% | 0.19% |  |
| C | 7542 | 6228 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7541 | 6227 | 166 | 166 | 2.20% | 2.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 273992 | 1629.98 | 845 | 833 | 167.6 |
| A | 13 | 254 | 12242 | 68.08 | 845 | 833 | 167.6 |
| A | 3 | 137 | 7761 | 41.34 | 845 | 833 | 167.6 |
| B | 6 | 159 | 1798710 | 11413.99 | 842 | 820 | 157.5 |
| B | 5 | 255 | 39495 | 245.53 | 842 | 820 | 157.5 |
| B | 0 | 190 | 22673 | 138.73 | 842 | 820 | 157.5 |
| C | 14 | 238 | 138004 | 710.6 | 832 | 841 | 193.0 |
| C | 3 | 233 | 115855 | 595.85 | 832 | 841 | 193.0 |
| C | 0 | 10 | 30692 | 154.65 | 832 | 841 | 193.0 |
| D | 10 | 253 | 455995 | 2094.34 | 824 | 812 | 217.3 |
| D | 12 | 227 | 391335 | 1796.83 | 824 | 812 | 217.3 |
| D | 8 | 195 | 91782 | 418.56 | 824 | 812 | 217.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
