| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T40_9000004458_30848cztM0_level2.evt | modeM0/AS1A10_071T40_9000004458_30848cztM0_level2_quad_clean.evt |
| Size (bytes) | 725,379,840 | 69,531,840 |
| Size | 691.8 MB | 66.3 MB |
| Events in quadrant A | 3,484,238 | 431,519 |
| Events in quadrant B | 10,349,808 | 403,441 |
| Events in quadrant C | 3,715,184 | 406,441 |
| Events in quadrant D | 3,972,636 | 402,534 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13983 | 2 |
| B | 0 | 35345 | 2 |
| C | 0 | 14769 | 2 |
| D | 0 | 15752 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6613 | 84 | 1.270225% |
| B | 6613 | 1971 | 29.804930% |
| C | 6613 | 193 | 2.918494% |
| D | 6612 | 88 | 1.330913% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7773 | 6614 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7773 | 6613 | 864 | 864 | 11.12% | 13.07% |  |
| C | 7773 | 6614 | 18 | 18 | 0.23% | 0.27% |  |
| D | 7772 | 6614 | 32 | 32 | 0.41% | 0.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12330 | 63.29 | 903 | 889 | 180.8 |
| A | 3 | 137 | 8662 | 43.0 | 903 | 889 | 180.8 |
| A | 0 | 226 | 7553 | 36.87 | 903 | 889 | 180.8 |
| B | 6 | 36 | 5208377 | 32420.25 | 841 | 821 | 160.6 |
| B | 6 | 159 | 1725494 | 10737.15 | 841 | 821 | 160.6 |
| B | 5 | 255 | 43277 | 264.31 | 841 | 821 | 160.6 |
| C | 0 | 10 | 184839 | 930.33 | 844 | 851 | 197.8 |
| C | 14 | 238 | 137312 | 690.01 | 844 | 851 | 197.8 |
| C | 3 | 233 | 73813 | 368.93 | 844 | 851 | 197.8 |
| D | 8 | 195 | 566227 | 2788.18 | 852 | 834 | 202.8 |
| D | 2 | 250 | 76510 | 373.19 | 852 | 834 | 202.8 |
| D | 12 | 233 | 40206 | 194.16 | 852 | 834 | 202.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
