| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T28_9000004464_30884cztM0_level2.evt | modeM0/AS1A10_071T28_9000004464_30884cztM0_level2_quad_clean.evt |
| Size (bytes) | 729,080,640 | 95,088,960 |
| Size | 695.3 MB | 90.7 MB |
| Events in quadrant A | 3,977,377 | 601,399 |
| Events in quadrant B | 8,073,080 | 573,710 |
| Events in quadrant C | 4,343,851 | 567,726 |
| Events in quadrant D | 5,130,536 | 565,465 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17019 | 2 |
| B | 0 | 29453 | 2 |
| C | 0 | 18055 | 2 |
| D | 0 | 20656 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 168 | 0 |
| B | 0 | 168 | 0 |
| C | 0 | 168 | 0 |
| D | 0 | 168 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8216 | 101 | 1.229309% |
| B | 8216 | 709 | 8.629503% |
| C | 8216 | 252 | 3.067186% |
| D | 8217 | 129 | 1.569916% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9846 | 8216 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9846 | 8216 | 353 | 353 | 3.59% | 4.30% |  |
| C | 9846 | 8216 | 57 | 57 | 0.58% | 0.69% |  |
| D | 9847 | 8217 | 14 | 14 | 0.14% | 0.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 15133 | 68.25 | 1029 | 1008 | 207.0 |
| A | 3 | 137 | 10679 | 46.73 | 1029 | 1008 | 207.0 |
| A | 0 | 226 | 8661 | 36.98 | 1029 | 1008 | 207.0 |
| B | 6 | 159 | 2320147 | 11880.79 | 1002 | 976 | 195.2 |
| B | 6 | 36 | 1628650 | 8338.35 | 1002 | 976 | 195.2 |
| B | 4 | 171 | 71804 | 362.84 | 1002 | 976 | 195.2 |
| C | 0 | 10 | 272606 | 1177.72 | 979 | 987 | 230.6 |
| C | 14 | 238 | 155297 | 669.08 | 979 | 987 | 230.6 |
| C | 3 | 233 | 70310 | 300.58 | 979 | 987 | 230.6 |
| D | 8 | 195 | 947165 | 4031.8 | 991 | 967 | 234.7 |
| D | 1 | 52 | 136223 | 576.33 | 991 | 967 | 234.7 |
| D | 7 | 238 | 123901 | 523.83 | 991 | 967 | 234.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
