| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T10_9000004472_30945cztM0_level2.evt | modeM0/AS1A10_058T10_9000004472_30945cztM0_level2_quad_clean.evt |
| Size (bytes) | 536,832,000 | 88,672,320 |
| Size | 512.0 MB | 84.6 MB |
| Events in quadrant A | 3,313,242 | 573,994 |
| Events in quadrant B | 5,294,953 | 573,444 |
| Events in quadrant C | 3,570,427 | 552,622 |
| Events in quadrant D | 3,649,993 | 543,020 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13925 | 2 |
| B | 0 | 20054 | 2 |
| C | 0 | 14654 | 2 |
| D | 0 | 15098 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6338 | 37 | 0.583780% |
| B | 6338 | 145 | 2.287788% |
| C | 6338 | 386 | 6.090249% |
| D | 6338 | 56 | 0.883559% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7533 | 6338 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7533 | 6338 | 16 | 16 | 0.21% | 0.25% |  |
| C | 7533 | 6338 | 9 | 9 | 0.12% | 0.14% |  |
| D | 7533 | 6338 | 24 | 24 | 0.32% | 0.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12046 | 65.88 | 854 | 840 | 170.1 |
| A | 11 | 47 | 8823 | 46.93 | 854 | 840 | 170.1 |
| A | 3 | 137 | 8312 | 43.93 | 854 | 840 | 170.1 |
| B | 6 | 159 | 1799259 | 11268.11 | 846 | 828 | 159.6 |
| B | 0 | 190 | 64376 | 398.16 | 846 | 828 | 159.6 |
| B | 5 | 172 | 58946 | 364.14 | 846 | 828 | 159.6 |
| C | 14 | 238 | 202115 | 1070.1 | 803 | 809 | 188.1 |
| C | 14 | 254 | 100448 | 529.66 | 803 | 809 | 188.1 |
| C | 0 | 10 | 96768 | 510.09 | 803 | 809 | 188.1 |
| D | 8 | 195 | 346350 | 1793.66 | 829 | 811 | 192.6 |
| D | 2 | 250 | 73595 | 377.82 | 829 | 811 | 192.6 |
| D | 15 | 47 | 49989 | 255.28 | 829 | 811 | 192.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
