| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T42_9000004476_30971cztM0_level2.evt | modeM0/AS1A10_071T42_9000004476_30971cztM0_level2_quad_clean.evt |
| Size (bytes) | 149,276,160 | 31,167,360 |
| Size | 142.4 MB | 29.7 MB |
| Events in quadrant A | 920,755 | 211,249 |
| Events in quadrant B | 1,416,153 | 212,057 |
| Events in quadrant C | 1,016,540 | 199,246 |
| Events in quadrant D | 1,051,898 | 198,300 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34 | 0 |
| B | 0 | 34 | 0 |
| C | 0 | 34 | 0 |
| D | 0 | 34 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3701 | 1 |
| B | 0 | 5252 | 1 |
| C | 0 | 4046 | 1 |
| D | 0 | 4251 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1671 | 66 | 3.949731% |
| B | 1671 | 115 | 6.882107% |
| C | 1671 | 118 | 7.061640% |
| D | 1671 | 63 | 3.770197% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2541 | 1671 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2541 | 1671 | 2 | 2 | 0.08% | 0.12% |  |
| C | 2541 | 1671 | 5 | 5 | 0.20% | 0.30% |  |
| D | 2541 | 1671 | 5 | 5 | 0.20% | 0.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 2766 | 50.69 | 238 | 232 | 50.0 |
| A | 3 | 137 | 2426 | 43.89 | 238 | 232 | 50.0 |
| A | 0 | 226 | 2054 | 36.45 | 238 | 232 | 50.0 |
| B | 6 | 159 | 452328 | 9529.9 | 231 | 225 | 47.4 |
| B | 0 | 190 | 13772 | 285.56 | 231 | 225 | 47.4 |
| B | 15 | 201 | 11878 | 245.63 | 231 | 225 | 47.4 |
| C | 0 | 10 | 95443 | 1741.82 | 223 | 223 | 54.7 |
| C | 14 | 238 | 35755 | 649.97 | 223 | 223 | 54.7 |
| C | 4 | 175 | 4450 | 77.32 | 223 | 223 | 54.7 |
| D | 8 | 195 | 109754 | 1873.47 | 233 | 226 | 58.5 |
| D | 2 | 250 | 31961 | 542.83 | 233 | 226 | 58.5 |
| D | 2 | 234 | 9150 | 152.64 | 233 | 226 | 58.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
