| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T48_9000004478_31000cztM0_level2.evt | modeM0/AS1A10_071T48_9000004478_31000cztM0_level2_quad_clean.evt |
| Size (bytes) | 493,070,400 | 92,623,680 |
| Size | 470.2 MB | 88.3 MB |
| Events in quadrant A | 2,968,125 | 611,061 |
| Events in quadrant B | 4,890,598 | 606,294 |
| Events in quadrant C | 3,219,536 | 578,564 |
| Events in quadrant D | 3,432,750 | 575,080 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12845 | 1 |
| B | 0 | 19030 | 3 |
| C | 0 | 13495 | 1 |
| D | 0 | 14160 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6219 | 40 | 0.643190% |
| B | 6219 | 89 | 1.431098% |
| C | 6219 | 143 | 2.299405% |
| D | 6219 | 57 | 0.916546% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7129 | 6219 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7129 | 6219 | 12 | 12 | 0.17% | 0.19% |  |
| C | 7129 | 6219 | 20 | 20 | 0.28% | 0.32% |  |
| D | 7129 | 6219 | 25 | 25 | 0.35% | 0.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11588 | 69.92 | 768 | 751 | 155.0 |
| A | 3 | 137 | 7686 | 44.75 | 768 | 751 | 155.0 |
| A | 0 | 226 | 6475 | 36.93 | 768 | 751 | 155.0 |
| B | 6 | 159 | 1730710 | 11904.23 | 754 | 735 | 145.3 |
| B | 0 | 155 | 64196 | 436.69 | 754 | 735 | 145.3 |
| B | 0 | 190 | 37169 | 250.71 | 754 | 735 | 145.3 |
| C | 0 | 10 | 125089 | 719.48 | 729 | 732 | 172.8 |
| C | 14 | 238 | 117262 | 674.2 | 729 | 732 | 172.8 |
| C | 3 | 233 | 64870 | 371.08 | 729 | 732 | 172.8 |
| D | 8 | 195 | 246919 | 1399.84 | 741 | 722 | 175.9 |
| D | 2 | 250 | 129544 | 732.46 | 741 | 722 | 175.9 |
| D | 12 | 33 | 63704 | 358.1 | 741 | 722 | 175.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
