| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T52_9000004480_31004cztM0_level2.evt | modeM0/AS1A10_071T52_9000004480_31004cztM0_level2_quad_clean.evt |
| Size (bytes) | 389,263,680 | 57,744,000 |
| Size | 371.2 MB | 55.1 MB |
| Events in quadrant A | 2,331,290 | 369,822 |
| Events in quadrant B | 3,800,767 | 374,277 |
| Events in quadrant C | 2,736,641 | 344,877 |
| Events in quadrant D | 2,611,399 | 339,782 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9784 | 1 |
| B | 0 | 14223 | 1 |
| C | 0 | 11053 | 1 |
| D | 0 | 10878 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 92 | 0 |
| B | 0 | 92 | 0 |
| C | 0 | 92 | 0 |
| D | 0 | 92 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4547 | 58 | 1.275566% |
| B | 4547 | 109 | 2.397185% |
| C | 4547 | 185 | 4.068617% |
| D | 4547 | 111 | 2.441170% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5832 | 4547 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5832 | 4547 | 3 | 3 | 0.05% | 0.07% |  |
| C | 5832 | 4547 | 65 | 65 | 1.11% | 1.43% |  |
| D | 5832 | 4547 | 73 | 73 | 1.25% | 1.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8848 | 67.6 | 604 | 594 | 122.1 |
| A | 3 | 137 | 5859 | 43.12 | 604 | 594 | 122.1 |
| A | 0 | 226 | 5175 | 37.52 | 604 | 594 | 122.1 |
| B | 6 | 159 | 1355095 | 11887.36 | 599 | 586 | 113.9 |
| B | 3 | 209 | 24327 | 208.35 | 599 | 586 | 113.9 |
| B | 4 | 52 | 18494 | 157.16 | 599 | 586 | 113.9 |
| C | 0 | 10 | 390031 | 2906.88 | 570 | 576 | 134.0 |
| C | 14 | 238 | 94226 | 699.0 | 570 | 576 | 134.0 |
| C | 2 | 114 | 10866 | 76.8 | 570 | 576 | 134.0 |
| D | 8 | 195 | 335864 | 2458.94 | 575 | 560 | 136.4 |
| D | 12 | 218 | 41144 | 297.62 | 575 | 560 | 136.4 |
| D | 2 | 234 | 19270 | 137.21 | 575 | 560 | 136.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
